14HR1403 12V stepper motor

14HR Stepper Motor -35mm(0.9 degree)
Low noise stepper motor with small dimensions (diameter 36mm). This motor has an accuracy of + - 5%, with a slope of 0.9 degrees degrees on each stepnya. For normal operation of this motor requires a voltage of 12V with a current consumption of 0.3A.

General Specs:

Step Accuracy ------------------------------ ±5%
Resistance Accuracy ----------------------- ±10%
Inductance Accuracy ---------------------- ±20%
Temperature Rise -------------------------- 80°C MAX.
Ambient Temperature Range ------------- -20°C~ +50°C
Storage Temperature Range ------------- -30°C~ +60°C
Insulation Resistance ---------------------- 100M Ω MIN. 500V DC
Dielectric Strength ------------------------- 500V AC 1min
Radial Play --------------------------------- 0.02mm MAX. (450g Load)
End Play ------------------------------------ 0.08mm MAX. (450g Load)
Max. radial force --------------------------- 28N
Max. axial force ---------------------------- 10N

8HY33-0204A Bipolar Stepper Motor

 8HY Miniature Stepper Motor -20mm(1.8 degree)

General specs:
Step Accuracy ------------------------------ ±5%
Resistance Accuracy ----------------------- ±10%
Inductance Accuracy ---------------------- ±20%
Temperature Rise -------------------------- 80°C MAX.
Ambient Temperature Range ------------- -20°C~ +50°C
Storage Temperature Range ------------- -30°C~ +60°C
Insulation Resistance ---------------------- 100M Ω MIN. 500V DC
Dielectric Strength ------------------------- 500V AC 1min
Radial Play --------------------------------- 0.02mm MAX. (450g Load)
End Play ------------------------------------ 0.08mm MAX. (450g Load)
Max. radial force --------------------------- 20N
Max. axial force ---------------------------- 2N

SR402P metal gear Robot Servo

Robot Servo,metal gears,single ball bearing,rotation range180°.

Products packing        ◇Packing with color box
            Packaging content:Servo×1 PCS、Servo arm×1bag、Manual×1 PCS
            Packaging specifications:Size-57×38×48mm、Net weight-66g、 Gross weight-76.2g
       ◇General packing(PE bag)
            Packaging content:Packing with PE bag
            Packaging specifications:PE bag size-120×85×0.07mm、Netweight-66g、Gross weight-71.4g

Products specificationTechnical parameters
Size (mm)WeightWire6.0V7.4VRotation angle
41.421.242.8--662.33300.28.2114.08 0.189.6133.6180°
(Specifications are subjected to change without notice.)

2.4G Wireless nRF24L01p with PA and LNA

nRF24L01p(nRF24L01+) with PA and LNA is compatible with nRF24L01+(nRF24L01p),and there are same interface. These are add a power amplifier(PA) circuit and Low Noise Amplifier(LNA) circuit, which could transmit longer distances and more stable performance for industry standard.Increased PA and LNA, RF switch, band pass filter,formed a professional full two-way RF power amplifier, making effective communication for greatly increased.The transmission distance to reach 1000 meter with 2DB Antenna at 250kbps data rate on open area.


  • Worldwide 2.4GHz ISM band operation,Free license to use.
  • 126 RF channels.
  • High air data rate: 250kbps, 1 and 2Mbps.
  • Transmitter: 11.3mA at 0dBm output power.
  • Receiver: Fast AGC for improved dynamic range.
  • Receiver: Integrated channel filters.
  • Enhanced ShockBurst™:1 to 32 bytes dynamic payload length,6 data pipe MultiCeiver™ for 1:6 star networks.
  • Host Interface:4-pin hardware SPI,3 separate 32 bytes TX and RX FIFOs.
  • Low Power Management:1.9 to 3.6V supply range.
  • GFSK modulation.
  • Auto packet transaction handling.
  • Easy for designed.
  • Small size:16.5mm*45.5mm.

Application Ideas

  • Wireless PC Peripherals
  • Mouse, keyboards and remotes
  • 3-in-1 desktop bundles
  • Advanced Media center remote controls
  • VoIP headsets
  • Game controllers
  • Sports watches and sensors
  • RF remote controls for consumer electronics
  • Home and commercial automation
  • Ultra low power sensor networks
  • Active RFID
  • Asset tracking systems
  • Toys

nRF24L01 module

This module based on Nordic nRF24L01, highly integrated, ultra low power (ULP) 2Mbps RF transceiver for the 2.4GHz ISM (Industrial, Scientific and Medical) band.  Nordic nRF24L01+ integrates a complete 2.4GHz RF transceiver, RF synthesizer, and baseband logic including the Enhanced ShockBurst™ hardware protocol accelerator supporting a high-speed SPI interface for the application controller.

  • Worldwide license-free 2.4GHz ISM band operation
  • 250kbps, 1Mbps and 2Mbps on-air data-rate options
  • Enhanced ShockBurst™ hardware protocol accelerator
  • Ultra low power consumption – months to years of battery lifetime
  • Power supply : 1.9~3.6V
  • IO port working voltage :  0~3.3v / 5v
  • Transmitting rate : +7dB
  • Receiving sensitivity : ≤ -90dB
  • Transmission range : 250m in open area
  • Dimension : 15x29mm

SIM908 Quad-Band GSM/GPRS + GPS module

SIM908 module is a complete Quad-Band  GSM/GPRS module which combines GPS technology for satellite navigation. The compact design which integrated GPRS and GPS in a SMT package will  significantly save both time and costs  for customers to develop GPS enabled applications.
Featuring an industry-standard interface and GPS function, it allows variable assets to be tracked seamlessly at any location and anytime with signal coverage.

General features
•Quad-Band 850/900/18001900MHz
•GPRS multi-slot class 10
•GPRS mobile station class B
•Compliant to GSM phase 2/2+
  -  Class 4 (2 W @ 850/900 MHz)
  - Class 1 (1 W @ 1800/1900MHz)
•Control via AT commands (GSM 07.07 ,07.05   and SIMCom enhanced AT Commands)
•SIM application toolkit
•Supply voltage range:
  -GPRS: 3.2 ~ 4.8 V
  -GPS: 3.0 ~ 4.5V
•Low power consumption
•Dimensions: 30*30*3.2mm
  - SIM908:5.2g
  - SIM908-C:11.1g
•Operation temperature:
  -40 °C to +85 °C

Specifications for SMS via GSM / GPRS •Point-to-point MO and MT
•SMS cell broadcast
•Text and PDU mode
Specifications for audio
  - Half rate (HR)
  - Full rate (FR)
  - Enhanced Full rate (EFR)
•Hands-free operation
•Echo cancellation

Specifications for data transfer
•GPRS class 8/10: max. 85.6 kbps (downlink)
•PBCCH support
•Coding schemes CS 1, 2, 3, 4
•CSD up to 14.4 kbps
•Non transparent mode
•Integrated TCP/IP stack

Compatibility •AT cellular command interface

Specification for GPS
•Receiver type
  - 42-channel
  - GPS L1 C/A code,
  - High-performance STE engine
  - Tracking:   -160 dBm
  - Cold starts :           -143 dBm
  - Cold starts:           30s (typ.)
  - Hot starts:   1s (typ.)
  -Horizontal position : <2 .5m="" br="" cep="" nbsp="">•Power consumption (GSM engine in idle mode)
  - Acquisition           77mA
  - Tracking   76mA
•80-pad with SMT type
•Interface to external SIM 3V/ 1.8V
• Dual analog audio interfaces
•SPI interface
•RTC backup
•Charge interface
•A serial interface and a debug interface for  GSM/GPRS
•Debug interface for GPS NMEA information output
•Two separate antenna connectors for GSM/GPRS&GPS

SIM18 GPS module

A GPS module with low power supply between 1.71 to 1.89 volts DC. This module has a number of channels more than the GPS in general, ie up to 48 channels.

- Power supply: 1.71 to 1.89 V
- Controller: SIM Com SIM18
- Working frequency: 1575.42 MHz L1
- Accuracy of position: 2.5m CEP (Circular Error Probability)
- Accuracy rate: <0:01 m="" nbsp="" p="" s="">- Number of satellite reception: 48 Channel SiRF4 engine
- Hot start: 0.6 seconds
- Warm start: <33 nbsp="" p="" seconds="">- Cold start: 35 ~ 40 seconds
- Format Data mapping: -
- Data format: NMEA, OSP
- Interface: UART, SPI, or I2C
- Antenna (internal / external) External

84X48 Graphic LCD - Nokia 5110

The Nokia 5110 is a basic graphic LCD screen for lots of applications. It was originally intended for as a cell phone screen. This one is mounted on an easy to solder PCB.
It uses the PCD8544 controller, which is the same used in the Nokia 3310 LCD. The PCD8544 is a low power CMOS LCD controller/driver, designed to drive a graphic display of 48 rows and 84 columns. All necessary functions for the display are provided in a single chip, including on-chip generation of LCD supply and bias voltages, resulting in a minimum of external components and low power consumption. The PCD8544 interfaces to microcontrollers through a serial bus interface.

Note: There may be small blemishes on these screens as they are surplus.
Note: Your screen may or may not have a diode on the PCB. It does not affect performance and will vary depending on our shipment.
Dimensions: 45x45mm

5Mpx camera modul for raspberry pi

RPI CAMERA BOARD plugs directly into the CSI connector on the Raspberry Pi. It's able to deliver a crystal clear 5MP resolution image, or 1080p HD video recording at 30fps with latest v1.3. Board features a 5MP (2592 × 1944 pixels) Omnivision 5647 sensor in a fixed focus module. The module attaches to Raspberry Pi, by way of a 15 pin Ribbon Cable, to the dedicated 15 pin MIPI Camera Serial Interface (CSI), which was designed especially for interfacing to cameras. The CSI bus is capable of extremely high data rates, and it exclusively carries pixel data to the BCM2835 processor.

  • Fully compatible with both the Model A and Model B Raspberry Pi
  • 5MP omnivision 5647 camera module
  • Still picture resolution of 2592 x 1944
  • Video supports 1080p at 30fps, 720p at 60fps and 640x480p 60/90 recording
  • 15 pin MIPI camera serial interface plugs directly into the Raspberry Pi Board
  • Size is 20mm x 25mm x 9mm
  • Weight of 3g
  • Fully compatible with the ModMyPi Raspberry Pi Case
Compatible with Raspberry Pi Model A/B/B+

SIM900 Quad Band GSM/GPRS Module

The SIM900 delivers GSM/GPRS 850/900/1800/1900MHz performance for voice, SMS, Data, and Fax in a small form factor and with low power consumption. With a tiny configuration of 24mm x 24mm x3 mm, SIM900 can fit almost all the space requirements in your M2M applications, especially for slim and compact demands of design.

General features
•Quad-Band 850/ 900/ 1800/ 1900 MHz
•GPRS multi-slot class 10/8
•GPRS mobile station class B
•Compliant to GSM phase 2/2+
– Class 4 (2 W @850/ 900 MHz)
– Class 1 (1 W @ 1800/1900MHz)
•SAIC (Single Antenna Interference Cancellation) support
•Dimensions: 24* 24 * 3 mm
•Weight: 3.4g
•Control via AT commands (GSM 07.07 ,07.05 and
SIMCOM enhanced AT Commands)
•SIM application toolkit
•Supply voltage range : 3.2 ... 4.8V
•Low power consumption: 1.0mA(sleep mode&BS-PAMFRMS=9 )
•Operation temperature: -40°C to +85 °C

Specifications for Fax
•Group 3, class 1

Specifications for GPRS Data
•GPRS class 10: max. 85.6 kbps (downlink)
•PBCCH support
•Coding schemes CS 1, 2, 3, 4

Specifications for CSD Data
•Non transparent mode

Specifications for SMS via GSM/GPRS
•Point to point MO and MT
•SMS cell broadcast
•Text and PDU mode

Software features
•0710 MUX protocol
•Embedded TCP/UDP protocol

Special firmware
•Embedded AT
•Java (cooperate with Iasolution)

Specifications for Voice
– Half rate (HR)
– Full rate (FR)
– Enhanced Full rate (EFR)
- Half rate (HR)
- Full rate (FR)
•Hands-free operation
(Echo suppression)

•Interface to external SIM 3V/ 1.8V
•Analog audio interface
•RTC backup
•SPI interface (option)
•Serial interface
•Antenna pad

•AT cellular command interface


Carrier Approvals:

M1-AVR-QF44 socket module for HILO All-100

Additional socket to the All-100. This socket can be used for IC 44-pin QFP models with dimensions (10x10mm). This socket supports IC ATMEGA 16 ATMEGA 16 L, XILINX, XC9536XL, XC9572XL. (QFP-44)

WSUB3G RF- Explorer Module

RFEMWSUB3G is an Expansion Module for RF Explorer. It can be plugged in your RF Explorer unit to extend the coverage to 15-2700 MHz (0.015-2.7GHz) continuous frequency band.
It gets attached internally to the RF Explorer main board and exhibits a second antenna connector to cover the new band.

  • Easy to plug in your RF Explorer unit, compatible with all models. Optionally, you may want to order a fully assembled RF Explorer 3G Combo including a WSUB1G base model and a RFEMWSUB3G expansion module.
  • Includes a transport EVA carry case for RF Explorer
  • Extend band coverage to any frequency starting at 15MHz and going up to 2.7GHz. This include very interesting frequency areas such as 2m HAM radio, all VHF and UHF, FM radio, GPS, WiFi and WiMax, Bluetooth, etc.
  • Extend internal FLASH and RAM memory for additional capabilities
  • Lifetime free firmware upgrades available, open to community requested features

  • Frequency band coverage: 15-2700 MHz
  • Standard SMA 50 ohms connector
  • Amplitude resolution: 0.5dBm
  • Dynamic range: -110dBm to -10dBm
  • Absolute Max input power: +30dBm
  • Average noise floor level (typical): -100dBm
  • 50 ohms wideband Nagoya NA-773 telescopic antenna included
  • Frequency stability and accuracy (typical): +-10ppm
  • Amplitude stability and accuracy (typical): +-6dBm
  • Frequency Span: 100MHz
  • Frequency resolution: 1Khz
  • Resolution bandwidth (RBW): automatic 3KHz to 600KHz
  • Expansion RAM: 64KB
  • Expansion ROM: 2MB
  • Firmware: RF Explorer must upgrade to firmware v1.09 or higher to use this module. Note some of the features and operation accuracy will be improved in upcoming lifetime free firmware revisions.

RF Explorer - ISM Combo

RF Explorer is a handheld digital spectrum analyzer, aimed to provide a very affordable tool for work in all ISM popular frequency bands. It is based on a highly integrated frequency synthesizer which offers high performance, compact size, low consumption and low cost.

It has been designed to be used equally well outdoor and indoor, and can be connected to a Windows PC using standard mini-USB for additional features and higher display resolution.


  • Pocket size and light weight
  • Solid aluminum metal case
  • Spectrum Analyzer mode with Peak Max, Normal and Averaging modes
  • Support all frequencies from 15 to 2700 MHz, including sub-1Ghz ISM bands and 2.4Ghz ISM band (Bluetooth, WiFi, ZigBee, etc).
  • Integrated RF Signal Generator for the ISM band of choice in a subset of models
  • Lifetime free firmware upgrades available, open to community requested features
  • High capacity Lipo for 16hs+ of continuous run, rechargeable by USB
  • Windows PC client Open Source
  • Internal expansion port for optional extensions with RF Explorer Expansion Modules


  • Currently available in six models, based on frequency range:
    • 433M: 430-440Mhz
    • 868M: 860-890Mhz
    • 915M: 910-920Mhz
    • WSub1G: 240-960MHz
    • 2.4G: 2350-2550MHz
    • 3G: 15-2700MHz
  • Current Expansion Modules available:
    • RFEMWSub1G: 240-960MHz
    • RFEM2.4G: 2350-2550MHz
    • RFEMWSUB3G: 15-2700MHz
  • Graphics LCD 128x64 pixels, great visibility outdoors
  • PC Windows client supports Windows XP\Vista\Win7 both 32 and 64bits
  • Mac OSX client - version available created by independent developer
  • Backlight for great indoor visibility
  • Standard SMA 50 ohms connector
  • Matching antenna included for selected frequency band
  • Amplitude resolution: 0.5dBm
  • Dynamic range: -115dBm to 0dBm (depends on the model)
  • Absolute Max input power: +5dBm
  • Average noise level (typical): -115dBm (depends on the model)
  • RF Generator amplitude: -30dBm to 21dBm (depends on the model)
  • Included matched and calibrated antenna
  • Frequency stability and accuracy (typical): +-10ppm
  • Amplitude stability and accuracy (typical): +-3dBm
  • Frequency resolution: 1Khz
  • Frequency Span: 112KHz - 600MHz (depends on the model)
  • Resolution bandwidth (RBW): automatic 2.6Khz to 800Khz (depends on the model)
  • Weight: 185g
  • Size: 113x70x25 mm

AM4113-N5UT Dino-Lite Premier (Nail Scope)

AM4113-N5UT Dino-Lite Premier
Observe and document nail blood circulation to check for healthy blood artery condition.


ModelAM4113-N5UT Dino-Lite Premier
InterfaceUSB 2.0
Product Resolution1.3M pixels (SXGA)
Magnification Rate500x
SensorColor CMOS
Frame RateUp to 30fps
Save FormatsImage:
DinoXcope: PNG, JPEG

DinoCapture2.0: WMV, FLV, SWF
DinoXcope: MOV
MicrotouchTouch sensitive trigger on the microscope for taking pictures
Lighting8 white LED lights switched on/off by software
Operating System SupportedWindows 8, 7, Vista, XP
MAC OS 10.4 or later
Unit Weight100(g)
Unit Dimension9.4cm (H) x 3.2cm (D)
Package Dimensions16cm (L) x 16cm (W) x 6cm (H)

Wednesday, September 24, 2014

AMH-DUT Dino-Lite Dentiscope (USB)

AMH-DUT Dino-Lite Dentiscope (USB)
Digitize your dental examination

Attach the tool grip tool to Dino-Lite gear for inspection, Dino-Lite digital microscope portable AMH-DUT Dentiscope an innovative way to analyze and make the data widely as images and videos.

With AMH-DUT, you can use a different gear checker tool with the tool holder, such as dental mirror. Holders loosen enough to remove or add dental tools. Dental tool holder can also be rotated around the scope of teeth 90 degrees at a time. You can also use the AMH-DUT without dental tool and use it as an external camera.

Dino-Lite handheld digital microscope works with software "DinoCapture" to "capture" either a photograph, video with a simple touch.

  • Model AMH-DUT Dino-Lite Dentiscope (USB)
  • Interface USB 2.0
  • Product Resolution 1.3M pixels (SXGA)
  • Magnification Rate 20x~30x
  • Sensor Color CMOS
  • Frame Rate Up to 30fps
Save Formats Image:
DinoCapture1.0: BMP, JPG
DinoXcope: PNG, JPEG
DinoCapture1.0: AVI
DinoCapture2.0: WMV, FLV, SWF
DinoXcope: MOV
  • Microtouch Touch sensitive trigger on the microscope for taking pictures
  • Lighting 8 white LED lights switched on/off by software
  • Measurement Function Yes
  • Calibration Function Yes
  • Operating System Supported Windows 8, 7, Vista, XP
  • MAC OS 10.4 or later
  • Unit Weight 95(g) +/- 10(g)
  • Unit Dimension 10cm (H) x 3.2cm (D)
  • Package Dimensions 16cm(L) x 16cm(W) x 6cm (H)

Comparison of Single Board Computer

Comparison of Single Board Computer

NameModelRelease datePrice rangeSoC
Arduino UnoR32010/091Atmel ATmega328P
armStoneA52013/025Freescale Vybrid VF6xx
armStoneA8[2011/02?Samsung S5PV210
armStoneA920125Freescale i.MX6
Arndale Board5250-AA2012/105Samsung Exynos 5 Dual (5250)
Arndale Octa2013/105Samsung Exynos 5 Octa (5420)
Banana Pi2014/031Allwinner A20
BeagleBoardD2012/103TI OMAP 3530
BeagleBoard-xM2010/094TI Sitara AM37x
BeagleBoneA62011/102TI Sitara AM335x
BeagleBone BlackC2013/041TI Sitara AM335x
Cosmic+ Board2013/072Freescale Vybrid VF6xx
Cubieboard2012/092Allwinner A10
Cubieboard 22013/062Allwinner A20
Cubieboard 32013/103Allwinner A20
Cubox-ii2, i2eX, i4Pro2013/112-4Freescale i.MX6
DreamPlug2011/024Marvell Kirkwood 88F6281
Embest SBC8600B2013/015TI Sitara AM3359
Foxconn AT-55702012/114AMD C-Series C-70 APU + AMD A45 FCH
GameStick2013/112Amlogic 8726-MX
Gizmo Board2013/025AMD Embedded G-Series T40E APU+ AMD A55E FCH
Gumstix Overo EarthSTORM+ Summit2012/014TI Sitara AM3703
Hackberry A102012/092Allwinner A10
HummingBoardi1, i2, i2eX2014/071-3Freescale i.MX6
IFC64102013/044Qualcomm Snapdragon 600 (APQ8064M)
Intel GalileoGen 22014/072Intel Quark SoC X1000
Intel NUC Board DE3815TYBE2014/043Intel Atom E3815
MarsBoardA10 New??Allwinner A10
MarsBoardA20 New?2Allwinner A20
MarsBoardRK30662014/052Rockchip RK3066
MinnowBoard2013/044Intel Atom E640 + Intel EG20T PCH
MiraBox2014/064Marvell Armada 370
MK808??2Rockchip RK3066
MTB025?2013/011VIA WonderMedia WM8850
MYIR MYD-AM335X2013/124TI Sitara AM335x
Netduino Plus 22012/111STMicro STM32 F4
Nitrogen6xRev 32013/065Freescale i.MX6 Quad
NovenaJust the board,
Desktop, Laptop,
Heirloom Laptop
2014/055Freescale i.MX6 Quad
Nvidia Jetson TK12014/045Nvidia Tegra K1
ODROID-U32014/012Samsung Exynos 4 Quad
ODROID-W2014/081Broadcom BCM2835
ODROID-XU20135Samsung Exynos 5 Octa (5410)
ODROID-XU32014/085Samsung Exynos 5 Octa (5422)
OLinuXino A10LIME?1Allwinner A10
OLinuXino A13base, MICRO, WIFI?1-2Allwinner A13
OLinuXino A20LIME, MICRO2013/061-2Allwinner A20
Ouya?20133Nvidia Tegra 3
PandaBoard ESRev. 32011/125TI OMAP 4460
pcDuino Lite2013/101Allwinner A10
pcDuino v22013/092Allwinner A10
pcDuino32014/022Allwinner A20
pcDuino3 Nano2014/07?Allwinner A20
PC Engines APUAPU.1C, APU.1D42014/044AMD Embedded G-Series T40E APU
Radxa Rockbase, Lite2014/012-3Rockchip RK3188
Raspberry PiModel A, B, B+2012/02 (A)
2012/10 (B)
2014/07 (B+)
1Broadcom BCM2835
Rikomagic MK802base, + / II?1Allwinner A10
RIoTboard?2014/012Freescale i.MX6 Solo
RouterBOARD RB450G2012/123Qualcomm Atheros AR7161
RouterBOARD RB953GS-5HnT2014/064Qualcomm Atheros QCA9558
SnowballSKY-S95002011/081ST-Ericsson NovaThor A9500
TBS 2910 Matrix2014/014Freescale i.MX6 Quad
UDOODual Lite, Dual, Quad2013/103-4Freescale i.MX6 + Atmel SAM3X8E
UtiliteValue, Standard, Pro2013/073-5Freescale i.MX6
VIA APC 8750 / Rock2012/051-2WonderMedia WM8750
VIA EPIA P9102012/125VIA Nano QuadCore L4650E + VIA VX11H
VIA Springboard VAB-6002013/113WonderMedia WM8950
WandboardSolo, Dual, Quad20133-4Freescale i.MX6
Price range : approximate price as of August 2014, grouped in these intervals:
  1. Lowest cost, corresponding to 0-49 USD;
  2. Low cost, corresponding to 50-79 USD;
  3. Medium cost, corresponding to 80-119 USD;
  4. High cost, corresponding to 120-169 USD;
  5. Highest cost, corresponding to 170 USD and higher.
