Wednesday, December 29, 2010

Protek 6500 series, analog oscilloscope

The Protek 6500 series analog oscilloscope available in 4 types:
  • 6502 (20 MHz Bandwidth)
  • 6504 (40 MHz Bandwidth)
  • 6506 (60 MHz Bandwidth)
  • 6510 (100 MHz Bandwidth)
General Features:
  • X-Y operation analog oscilloscope
  • 2 Channel , 4 Traces
  • 12KV CRT / A, B Sweep Time delay for Type 6510
  • 5 Times Magnifier for type 6502
  • 10 Times Magnifier for type 6504, 6506 & 6510

Solder , by Goot (Japan)

Goot Electric Solder , reliable and durable. available in type:
Economically priced general purpose soldering iron.
•Compact and lightweight design for easy handling.
•Available with Longlife tip or Nickel plated conventional copper tip.

General Specification: V in = 110/220 VAC , 50/60Hz

Thursday, December 23, 2010

Merry Christmas & Happy New Year 2011

Wish you Merry Christmast & Happy New Year 2011

Sennheiser HD 800

More than 60 years of ingenious headphone engineering has been applied into the new HD 800. Incorporating Sennheiser’s most advanced driver technology, these open, circum-aural dynamic stereo headphones redefine what reference-level audio is all about. You will form an altogether new height of sonic perspective as you experience a high-fidelity natural hearing experience. Do take note that presently, no other manufacturer has been able to come up as close as the HD 800 in replicating the basic acoustic conditions of natural hearing.

Matching these headphones' reference-grade audio performance is their striking and visually effective industrial design. Premium parts have gone into their production - the transducer is encased by a precision material made of stainless steel. The ear pads are handcrafted from a high-quality microfiber fabric. This material is extremely comfortable to wear and easy to maintain. The headband and headphone mounting utilises the most advanced development from the aerospace industry. In terms of connectivity, these headphones utilise specially-designed, four-wire, high-performance connections with Teflon insulation.

Truly, the HD 800 are a glorious success and have become a pioneer in headphone development.

HD 800 – Crafted for perfection.

Features

* New reference class in wired headphones
* Open, circum-aural dynamic stereo headphones
* Natural hearing experience - realistic and natural sound field with minimal resonance
* Biggest transducers ever used in headphones up to today - new innovative dynamic transducer design
* Uncovered earcups for acoustic and stylistic reasons
* Handcrafted ear pads, made of high-quality microfiber fabric
* Metal headband with inner damping element
* Specially tuned symmetrical, impedance matching cable with low capacitance
* Special high precision headphone connectors
* 2 year warranty

Technical Specs:
6 – 51000 Hz (-10 dB)
14 – 44100 Hz (- 3 dB)
dynamic, open
300 Ω
102 dB
≤0.02 % (1kHz/1Vrms)
3.4 N (± 0.3 N) approx.
circumaural
Weight w/o cable
330 g
¼” (6.3 mm) stereo
3m


Sennheiser IE 7

The IE 7 are a pair of high-fidelity, noise-isolating ear-canal phones which deliver an audio reproduction that is balanced, precise and true-to-life. The unique ear-pieces ensure an optimum fit and a high level of noise attenuation. The IE 7 durable housing and rugged cable provide maximum durability. The ergonomic ear-canal phones come complete with an assortment of ear adapters, a deluxe protective case, a cleaning tool and a cable clip. The IE 7 are optimised for professional monitoring use and ideal for portable AV devices like MP3, DVD and CD players, iPods, iPhones (iPhone and iPod are registered trademarks of Apple Inc. in the U.S. and other countries), or any other mobile phone with a 3.5mm stereo jack.
IE 7 by Sennheiser
Features

* Dynamic drivers with powerful neodymium magnets for a balanced, precise and true-to-life sound
* Excellent attenuation of ambient noise
* Durable housing and rugged, high-performance cable
* Sleek ergonomic design and various types and sizes (S/M/L) of ear adapters ensure a comfortable, secure fit
* Optimised for professional monitoring use and ideal for for MP3, iPod, iPhone, DVD and CD players, and mobile phones (3.5mm stereo plug)
* 2-year warranty


Delivery Includes

* 1 IE 7
* 1 set of ear adapters (S/M/L)
* 1 protective case
* 1 cleaning tool
* 1 cable clip

Technical Specs:

Frequency response
10 Hz - 19000 Hz
1.2 m, symmetrical (earphone to separator: 0.4 m; separator to plug: 0.8 m)
16 Ω
< 0.1%
120 dB
up to 20 dB (90%)
3.5 mm, angled
intraaural
dynamic
Weight
5 g

Sennheiser HD 595

The open, dynamic HD 595s open up a new dimension in headphone sound and comfort. Sennheiser’s most advanced driver technology is used here, combining exceptional clarity with outstanding musicality. The unique E.A.R. design channels music directly into the user’s ears, creating a new kind of listening experience. The HD 595s come with a clever headphone bracket that easily attaches to a table or shelf, making sure that the headphones are always at hand.

Features

* Enjoy music in a completely new way: “Eargonomic acoustic refinement” (E.A.R.) design channels the audio signal directly into your ears
* Advanced Duofol diaphragm technology almost eliminates standing waves inside the capsule
* Optimized neodymium ferrous magnet systems
* Outstanding wearing comfort for long listening sessions
HD595 by Sennheiser
* Long life due to easily replaceable parts
* Lightweight aluminium voice coils for high efficiency and excellent dynamics
* Extremely comfortable velour ear pads
* Special diaphragm geometry reduces intermodulation distortion
* Highly constant, compressed cellulose fleece reduces total harmonic distortion
* Headphone holder included – easily attached to a table or shelf

Delivery Includes

* HD 595 headphones
* Adaptor to 3.5mm jack
* Headphone holder
Technical Specs:
Nominal impedance 50 Ω
Contact pressure 3,5 N
Weight w/o cable  270 g
Jack plug 6,3 mm stereo (3,5 mm Adapter)
Transducer principle (Headphones) dynamic, open
Ear coupling circumaural
Cable length 3 m
Frequency response (headphones) 12 - 38500 Hz
Sound pressure level (SPL) 112 dB
THD, total harmonic distortion < 0,1 %

Thursday, December 16, 2010

3Com® OfficeConnect® Dual Speed Switch 16, type 3C16792A

3Com® OfficeConnect® Dual Speed Switch 16, type 3C16792A
Seamless 10/100 Ethernet Switching
The 3Com® OfficeConnect® Dual Speed Switch 16 is designed for small offices and remote branch offices requiring high network performance to exchange large data files and images, and access real-time information. Expand your network by adding more computers or devices with speeds up to 200 Mbps per port in full-duplex mode.

This switch automatically finds the fastest connection speed, with the autosensing 10/100 ports automatically adjusting to the speed of network devices communicating at 100 or 10 Mbps, so the switch can accommodate a range of workgroup applications. Automatic MDI/MDIX on every port simplifies network expansion by eliminating most common cabling errors. All that is needed is to connect the power and Ethernet cables.

There is no software to configure. Easy to set up, these switches feature a fanless design which provides silent operation.

Features:
# With plug-and-play installation and no configuration needed, the switch fits easily into your unmanaged network
# Automatic MDI/MDIX on every port simplifies network expansion by eliminating most common cabling errors
# Sixteen autosensing ports automatically detect the speed of the attached device to maximize network performance
# With plug-and-play installation and no configuration needed, it fits easily in your unmanaged network
# Full-duplex feature supports two-way data transfer, doubling the effective bandwidth of the network
# Compact, fanless design ensures quiet operation in small office spaces
# Connectors at rear help reduce cable clutter

Technical specs:
# Total ports: 16 autosensing 10/100 Ethernet
# Media interfaces: 10/100BASE-TX/RJ-45
# Ethernet switching features: Store-and-forward; full-/half-duplex autonegotiation
# Height: 54.6 mm (2.1 in)
# Width: 228 mm (9.1 in)
# Depth: 185.4 mm (7.3 in)
# More specifications: See the OfficeConnect Switch data sheet for complete specifications
Package Contents
# Switch
# Power supply unit
# Clipping system
# Rubber feet
# User's guide

Tuesday, December 14, 2010

ACOS3 Microprocessor Card

The ACOS3 Microprcoessor Card (Advanced Card Operating System) unlocks the potential of a smart card. It enables a single card to support various applications such as loyalty program, parking registration, network access control, public transportation, telecommunication, and electronic purse.

ACOS3 is specifically designed for highly secure payment applications. Featuring a high degree of security, ACOS3 is particularly suitable for secure loyalty programs, network access control and epurse applications. Likewise, it may be utilized for common payment solutions.

Additionally, security provided by ACOS3 can be enhanced further by utilizing ACOS6-SAM, which, by enabling Mutual Authentication, Secure Messaging and Key Diversification, perfectly secures various applications.

Features:
  • Full 32/72 Kbytes of EEPROM memory for application data
  • Compliance with ISO 7816 parts 1, 2, 3; supporting the T=0 direct protocol
  • ISO7816-2 compliant 8-contact module
  • High-speed transmission possible (9.6 to 223.2 kbps) with modifiable ATR.
  • DES / 3DES and MAC capabilities
  • Five secret codes + issuer code
  • PIN code that can be updated by card holder
  • Key pair for mutual authentication
  • Session key based on FIPS140-2 compliant true random numbers
  • Transparent files and linear files with fixed record length are available.
  • Secure messaging option ensures transmission of user data is secured against eavesdropping, replay attack and unauthorized modifications.
  • Account data structure for highly secure payment applications as an optional feature
  • Completely backward compatible with ACOS1 / ACOS2 cards.
Application:
  • E-purse application
  • E-Payment
  • Customer loyalty
  • Physical Access control
  • Corporate Identity
  • Healthcare management
  • Microsoft Windows Logon

D-Link DSL-2640B Wireless G ADSL2+ Modem Router

D-Link DSL-2640B Wireless G ADSL2+ Modem Router
Built-in 802.11g WLAN interface - up to 54Mbps speed - 4-Port 10/100 Switch - Built-in ISP Database - Advanced Parental Control - Firewall protection, Quality of Service (QoS)

ADSL2+ 4-port Modem Router
The D-Link DSL-2542B ADSL2+ 4-port Modem Router is an affordable, high-speed remote router for the home and small office. With an integrated ADSL modem, the router connects directly to your phone socket to allow several people to surf, chat or check e-mails on-line simultaneously.

High-Speed ADSL connection
The DSL-2542B supports the latest ADSL2/ADSL2+ standards, providing speeds of up to 24 Mbps downstream and 1 Mbps upstream (ADSL2+), or 12 Mbps downstream and 1 Mbps upstream (ADSL2). It is compatible with all major European service providers.

The heart of your network
The router includes four Ethernet ports, ready for you to connect network devices such as print servers, network cameras, digital media players and computers running any operating system.

Internet Security
The router features a comprehensive firewall that repels Denial of Service (DoS) attacks and prevents hackers from entering your network from the Internet. Strong parental controls allow you to block certain web site addresses, preventing users from viewing inappropriate content. This can be adjusted according to the time of the day (scheduling).
The router also supports multiple VPN pass-through to let you securely access office files and e-mail from home.

No delays with Internet phone calls and gaming
The router is able to identify those data packets that are sensitive to delay, such as in voice or games.
This support for Quality of Service (QoS) is automatic, but can also be configured for you to prioritise your own chosen applications.

Easy to install
The router includes D-Link's Click'n Connect software (DCC). This wizard allows anybody without any prior technical knowledge to install the router and connect to the Internet within minutes. Just by running the product CD, you are taken through establishing physical connections (power and cabling), selecting your ISP from the drop-down menu and finally connecting to the Internet.

D-link DSL-526B

DSL-526B
ADSL2+ Ethernet/USB Combo Router.

Affordable High-Speed Connection for Home & Small Office
The DSL-526B ADSL2+ combo modem router is an affordable high-performance ADSL device for home and the small office. With integrated ADSL2/2+ supporting up to 24Mbps download speed, firewall protection and Quality of Service (QoS), this router provides all the essentials that a home or small office needs to establish a secure and high-speed remote link to the outside world.

Firewall Protection & QoS
Security features prevents unauthorized access to the home and office network from Internet intruders. The router provides firewall security using Stateful Packet Inspection (SPI) and Denial of Service (DoS) attack protection. SPI inspects the contents of all incoming packet headers before deciding what packets are allowed to pass through. Router access control is provided with packet filtering based on port and source/destination MAC/IP addresses. For Quality of Service (QoS), the router supports multiple priority queues to enable a group of home or office users to experience the benefit of smooth network connection of inbound and outbound data without concern of traffic congestion. This QoS support allows users to enjoy high ADSL transmission for applications such as VoIP, streaming multimedia and on-line games over the Internet.

Device interfaces:
  • RJ-11 ADSL port
  • RJ-45 LAN 10/100 with auto MDI/MDIx
  • USB 1.1
  • auto reset button

Friday, December 10, 2010

3Com® Baseline Switch 2024 Product #: 3C16471

3Com® Baseline Switch 2024 Product #: 3C16471
Simple, Rich-Featured Switching for Diverse Users
Features & Benefits

Simple, Rich-Featured Switching for Diverse Users
The 3Com® Baseline Switch 2024is a 24-port unmanaged, 10/100 nonblocking switch designed for small to midsize offices. This rack mountable, business-class switch can be installed in a wiring closet or as a free-standing unit.

The switch comes preconfigured for fast, easy installation using economical copper wiring. Auto-negotiation adjusts the port speed to match the communicating device. Any of the switch's 24 ports can deliver 10BASE-T Ethernet for users with average bandwidth requirements, or 100BASE-TX Fast Ethernet for power users or those with newer network connections. To simplify connecting cables, all ports come with automatic detection of the Ethernet cable type (MDI/MDIX).
Like all 3Com Baseline products, this switch provides powerful, feature-rich practicality in a sturdy package designed for reliability, long life, and low total cost of ownership.

# Switch works right out of the box—no configuration or management software necessary
# Nonblocking performance means improved access to network resources
# 10/100 auto-negotiation automatically determines the correct port speed
# Automatic MDI/MDIX on all ports simplifies setup by enabling direct connection to another device using straight-through or crossover cables
# Sturdy design and build quality ensure reliable operation and long life
# Can be rack-mounted or stacked to maximize space; standard 1RU form factor simplifies space planning

Product Specifications
# Ports: 24 autosensing, auto-configuration MDI/MDIX 10BASE-T/100BASE-TX
# Media interfaces: RJ-45
# Ethernet switching features: Full-rate nonblocking on all Ethernet ports, full/half duplex auto-negotiation and flow control
# MAC addresses supported: 4,000
# Height: 4.4 cm (1.7 in)
# Width: 44 cm (17.3 in)
# Depth: 17.3 cm (6.8 in)
# Weight: 1.5 kg (3.07 lb)


Package Contents
# Switch
# Rubber feet
# Rack-mount kit
# User's guide

3Com® Baseline Switch 2016 Product #: 3C16470

 3Com® Baseline Switch 2016 Product #: 3C16470
Simple, Rich-Featured Switching for Diverse Users

Features & Benefits

The 3Com® Baseline Switch 2016 is a 16-port unmanaged, 10/100 nonblocking switch designed for small to midsize offices. This rack mountable, business-class switch can be installed in a wiring closet or as a free-standing unit.

The switch comes preconfigured for fast, easy installation using economical copper wiring. Auto-negotiation adjusts the port speed to match the communicating device. Any of the switch's 16 ports can deliver 10BASE-T Ethernet for users with average bandwidth requirements, or 100BASE-TX Fast Ethernet for power users or those with newer network connections. To simplify connecting cables, all 26 ports come with automatic detection of the Ethernet cable type (MDI/MDIX).

Like all 3Com Baseline products, this switch provides powerful, feature-rich practicality in a sturdy package designed for reliability, long life, and low total cost of ownership

Features:
# Switch works right out of the box—no configuration or management software necessary
# Nonblocking performance means improved access to network resources
# 10/100 auto-negotiation automatically determines the correct port speed
# Automatic MDI/MDIX on all ports simplifies setup by enabling direct connection to another device using straight-through or crossover cables
# Sturdy design and build quality ensure reliable operation and long life
# Can be rack-mounted or stacked to maximize space; standard 1RU

Product Specifications
# Ports: 16 autosensing, auto-configuration MDI/MDIX 10BASE-T/100BASE-TX
# Media interfaces: RJ-45
# Ethernet switching features: Full-rate nonblocking on all Ethernet ports, full/half duplex auto-negotiation and flow control
# MAC addresses supported: 4,000
# Height: 4.4 cm (1.7 in)
# Width: 44 cm (17.3 in)
# Depth: 17.3 cm (6.8 in)
# Weight: 1.5 kg (3.07 lb)

Package Contents
# Switch
# Rubber feet
# Rack-mount kit
# User's guide

Friday, December 03, 2010

DustEZE HEPA Vacuum Eraser

DustEZE Suit for School/Office/Home use to reduce the Chalk Eraser Chalk Dust Allergy Very Easy------
Revolutionary New Patented, 9-stage DustEZE 3 in One HEPA Cleaner.DustEZE Electric Vacuum Chalk Eraser Cleaner can clean all kinds of chalk eraser cleaner such as cotton chalk eraser ,sponge chalk eraser,felt chalk eraser in only seconds.
Innovation Electric Vacuum Chalk Eraser Cleaner with HEPA filtration, not only suit for all kind of chalkboard or marker board eraser clean,but also suit for duster and dry floor mop dusting.
DustEZE. Got Usa,Europe,China,Hongkong,India,Vietnam,Taiwan Worldwide Patent and USA/CANADA ETL+CETL SAFETY,EUROPE CE SAFETY,JAPAN PSE SAFETY ,CB SAFETY APPROVAL ,not only the motor but for DustEZE whole machine had got safety approval.
It is a very new innovative patented green product; it could reduce much more cost and labor not only for the school chalkboard and kids easel chalkboard Eraser cleaning but also suit for duster which can use in place to clean computer,whiteboard,screen,furniture and take care the health for teacher, student, and housewife.
Base on the 13 years experience for manufacture, 2nd DustEZE Multi Functional HEPA Vacuum Eraser Cleaner. We have many innovative in the new model, such as 9-stage HEPA Filtration ,dust full indicator, dustproof cover, dustproof cover misdirection protect,HEPA filter install failed protect,dustbag absent protect, replaceable slice brush, and so on,More safety and easy to maintain. , Lower power consumption, Long time low noise,. Prolong the life of DustEZE.
DustEZE has many advantage as following:

FEATURES:

(1)High Efficiency Particulate Air (HEPA) filter: set ahead the motor, can suck up the dust completely and keep the discharged air clean, also can prolong its life-DustEZE HEPA Vacuum Chalk Eraser Cleaner.
(2)Dust full indicator: when the dust bag or HEPA filter are full of dust, the“dust full indicator” will turn to red-DustEZE HEPA Vacuum Chalk Eraser Cleaner.
(3)Dustproof cover: This product is applied with exact hermetical also durable for cleanout structure. That make this appliance can keep clean inside and outside for a long time, also can keep dust from spreading effectively which will pollute those inner components. It also can reduce the time spend on maintenance and avoiding those spreading dust suck into motor for prolonging the life of motor-DustEZE HEPA Vacuum Chalk Eraser Cleaner.
(4)HEPA filter install failed protect function: While the HEPA filter is not installed, it will do not work for protecting motor and keeping dust from leaking-DustEZE HEPA Vacuum Chalk Eraser Cleaner.
(5)Dustbag absent protect function: If dustbag is absent or placed incorrectly, the top cover will can not be closed-DustEZE HEPA Vacuum Chalk Eraser Cleaner.
(6)Replaceable slice brush: Cleaning the dust thoroughly, if it is wore away, which can be replaced by oneself easily-DustEZE HEPA Vacuum Chalk Eraser Cleaner.
(7)Overheat protect function: Equip with“Reset thermostat protector”on the motor to prevent the motor from any breakage caused by overheat-DustEZE HEPA Vacuum Chalk Eraser Cleaner.
(8)Over loading of electric current protect function:
(a).100~120v:Apply with Non-fuse electric current switch can prevent the product from any damage caused by over loading of electric current. And it is no necessary to change fuse for instauration, but only press the reset button under the base-DustEZE HEPA Vacuum Chalk Eraser Cleaner.
(b).220~240v:It can prevent the product from any damage caused by over loading of electric current. And it is easy to change fuse-DustEZE
------------------------------------------------------------------------------------------------------------------------------------------------------
SPEC&PACKING
1.CE/CB/PSE/ETL+CETL SAFETY APPROVAL
2.100V/330w(JAPAN PSE SAFETY),120V/480w(USA/CANADA ETL+CETL SAFETY)
3.220-240v/400w(EUROPE CE+CB SAFETY)
4.PACKAGE SIZE:305(L)x170(W)x185(H)mm(1pcs);540(L)X330(W)X400(H)mm(6pcs)
5.G. W: 2. 6kg/N. W: 2. 3kg
6.20'/1,800PCS
7.MOQ:108PCS
8.MODEL:DustEZE EC560
9.SERIES NO:RH602560002

Thursday, December 02, 2010

Cisco-Linksys WAP610N Wireless-N Access Point with Dual-Band

Cisco-Linksys WAP610N Wireless-N Access Point with Dual-Band
Product Features

    * Add a Wireless-N (802.11n draft 2.0) network to an existing wired or wireless router
    * Optimized for video
    * Complies with IEEE 802.11n draft 2.0 (2.4 GHz and 5 GHz), 802.11g, 802.11b and 802.11a standards
    * Wi-Fi certiied to ensure interoperability
    * Industrial-strength wireless encryption WPA2 to ensure security

Technical Details


    * Brand Name: Cisco
    * Model: WAP610N
    * Hardware Platform: PC
    * Form Factor: External
    * Connectivity Technology: Wireless
    * Networking Feature: Wireless access point
    * Data Link Protocol: IEEE 802.11n (draft), IEEE 802.11b, IEEE 802.11a, IEEE 802.11g
    * Width: 5.7 inches
    * Depth: 2 inches
    * Height: 4.2 inches
    * Weight: 5.6 Ounces

Wednesday, December 01, 2010

3CFSU08 ,3Com® Switch 8 Port

3CFSU08 ,3Com® Switch 8 Port
Features & Benefits

Compact, Streamlined, Affordable Switching for Small Offices.
The 3Com® Switch 8 is designed for small offices and remote branch offices requiring high network performance to exchange large data files and images, and access real-time information. Featuring an internal power supply, autosensing and auto MDI/MDIX on all ports, the Switch 8 is delivered in a futuristic, compact and streamlined enclosure. With a high quality dark gun metal grey look these switches exude quality, the 3Com logos "light up" on power up and they feature illuminating blue LEDs.

The 3Com Switch 8 automatically finds the fastest connection speed, the autosensing 10/100 ports automatically adjust to the speed of network devices communicating at 100 or 10 Mbps, so the switch can accommodate a range of workgroup applications. All that is needed is to connect the power and Ethernet cables.

There is no software to configure. Easy to set up these switches feature a fan-less design which provides silent operation. With a choice of 8 ports you can expand your network by adding more computers or devices with speeds up to 200 Mbps per port in full-duplex mode.

For the most cost conscious, the 3Com Switch 8 offers high-speed, high-quality, reliable, affordable networking with a style that will accommodate any office environment and is backed by an outstanding 2-year warranty.

For those requiring smaller port counts a 5 port version of this switch is available, the Switch 5. Furthermore for situations where 10/100/1000 connectivity is required 5 and 8 port Gigabit versions of this switch are available, the 3Com Gigabit Switch 5 and 3Com Gigabit Switch 8 respectively.

Product Specifications


# Total ports: 8 autosensing 10/100 Ethernet
# Media interfaces: 8 RJ-45 10BASE-T/100BASE-TX
# Ethernet switching features: Store-and-forward; full-/half-duplex auto-negotiation
# Regulatory/Agency Approvals:
EMC:
CFR Title 47, FCC Part 15, Subpart B
Sections 15, 107 & 15, 109 Class B
ICES-003 Class B
EN 55022: Class B
EN 61000-3-2: 2000
EN 61000-3-3:1995
EN 61000-3-11
CISPR 22: 2003-04-10 Class B
RRL

Safety:
UL60950-1
CSA 22.2 No60950-1
EN60950-1
IEC6095-1

# Environmental Specifications:
Operating temperature: 0º to 40ºC (32º to 105ºF)
Operating Humidity: 10% to 90% (non-condensing humidity)
Storage Humidity: 0% to 95%

# Dimensions:
Width: 178 mm (7.0 in)
Height: 30.20 mm (1.18 in)
Depth: 108 mm (4.25 in)
Weight: 525g (1.16 lb)

# Power: 4.7W

Friday, November 26, 2010

Linksys SRW224G4P

Linksys SRW224G4P , 24-Port Managed Gigabit Switch with WebView and PoE .
24-Port Managed Gigabit Switch with WebView and PoE ,(24) 10/100 ports + (2) shared Gigabit combo ports + (2) Gigabit uplink ports

The Linksys WebView Managed switch allows you to expand your network securely. Configuration of the switch is secured using SSL for Web access. User control is secured using 802.1x security using a RADIUS authentication mechanism and can also be controlled using MAC filtering. Extensive QoS features makes the solution ideal for real-time applications like Voice and Video. The 4 priority queues together with the Weighted Round Robin and Strict Priority scheduling techniques facilitate efficient co-existence of real-time traffic with data traffic allowing them each to meet their QoS needs. Individual users or applications can be prioritized above others using various Class of Service options - by port, layer 2 priority (802.1p), and Layer 3 priority (TOS or DSCP). Intelligent Broadcast, and Multicast storm control minimizes and contain the effect of these types of traffic on regular traffic. IGMP Snooping limits bandwidth-intensive video traffic to only the requestors without flooding to all users. Incoming traffic can be policed and outgoing traffic can be shaped allowing you to control network access and traffic flow.

There are features that allow you to expand and grow your network of switches. Link aggregation allow multiple high-bandwidth trunks between switches to be setup. This also provides a level of reliability in that the system continues to operate if one of the links break. Spanning Tree (STP), Fast Spanning Tree, and Rapid Spanning Tree (RSTP) allow you to build a mesh of switches increasing the availability of the system.

The rich management functionality of the WebView switches includes SNMP, RMON, Telnet, and HTTP Management options, allowing you to flexibly integrate and manage these devices in your network.

Automatic Load Sensing - Power control circuitry automatically detects Power over Ethernet on access point before providing power. Power feeding of Ethernet limited for fixed 10/100 Base-T/TX ports. The solution can provide maximum output power per PoE port up to 15.4W on 24 ports simultaneously. Independent overload and short-circuit protection for each port. LED indicators for power status per PoE port. Support IEEE802.3af MIB for power over Ethernet function. Support IEEE 802.1d spanning tree, IEEE 802.1w Rapid STP, Fast Linkover, IEEE 802.1s Multiple STP. Cable diagnostics.

Benefits:
  • An ideal solution for expanding existing networks in growing companies
  • Standards-based IEEE 802.3af Power over Ethernet (PoE) - Up to 12 ports at 15.4W for 180W of total PoE power
  • Solution ideal for voice and video with IGMP snooping, L2/L3 policy filters
  • Secure management via SSH/SSL and secure user access via 802.1x Port Authentication and MAC address filtering
Features:
  • 24 - 10/100 Switched RJ-45 ports deliver up to 4 Gbps of throughput per port
  • 2 shared 10/100/1000 miniGBIC ports
  • Switching capacity delivers wirespeed performance at 12.8 Gbps, non-blocking capacity
  • WebView monitoring allows administrators to view the current status and configuration using their favorite web browser
  • PoE on 12 10/100 ports supplies up to IEEE 802.3af maximum of 15.4W per port
  • Auto MDI/MDIX per port allows for automatic Cable detection
  • Port based and 802.1q based VLAN’s support up to 256 VLANs
  • Port trunking for up to 8 groups allows you to increase your bandwidth for each uplink or Server connection
  • Port configuration settings for link, speed, auto MDI/MDIX, flow control, and more
  • Fully rack-mountable using the included rack-mounting hardware
  • MAC address table supports up to 8K MAC address entries
  • Optimal platform to support real-time applications like voice and video by providing features like IGMP snooping, multiple queues (4) with appropriate scheduling techniques, prioritization of traffic based on port, 802.1p, IP ToS/precedence/ DSCP, TCP/UDP port and line rate forwarding mechanisms
  • Enhanced QoS functions including rate limiting for ingress/egress and per flow at 64kbps granularity
  • Secure control via SSH for Telnet interface and SSL for HTTP interface
  • User/Network security via 802.1X (with RADIUS authentication) and MAC‑based filtering
  • Advanced security ACL can deny or limit network access based on L1-L4 information e.g. MAC, Ethernet type, VLAN ID, IP address, Protocol ID, or TCP/UDP port
  • Containment of storms - Broadcast and Multicast
  • Expandability and availability increased across multiple switches using Link Aggregation
  • Port trunking for up to 8 groups with up to 8 ports per group allows you to increase your bandwidth for each uplink or Server connection
  • SNMP and RMON management expand your visibility options

Specifications:


24-Port Managed Gigabit Switch with WebView and PoE
Specifications
Model Number SRW224G4P
Ports 24 RJ-45 connectors for 10BASE-T, 100BASE-TX and 1000BASE-T with 2 shared SFP slots and 2 giga ports
Standards 802.3 10BASE-T Ethernet, 802.3u 100BASE-TX Fast Ethernet, 802.3ab 1000BASE-T Gigabit Ethernet, 802.3z Gigabit Ethernet, 802.3x Flow Control, 802.3 ad LACP,802.3af PoE, 802.1d STP, 802.1Q/p VLAN, 802.1w Rapid STP, 802.1s Multiple STP, 802.1X Port Access Authentication
Cabling Type UTP CAT 5 or better for 10BASE-T/100BASE-TX, UTP CAT 5e or better for 1000BASE-T
LEDs Power, Link/Act, Speed
Performance
Switching Capacity 12.8 Gbps, non-blocking
MAC table size 8k
Number of VLANs 256
Management
Web User Interface Built-in Web UI for easy browser-based configuration (HTTP/HTTPS)
SNMP SNMP version 1, 2, 3 with support for traps
SNMP MIBs RFC1213 MIB-2, RFC2863 Interface MIB, RFC2665 Ether-like MIB, RFC1493 Bridge MIB, RFC2674 Extended Bridge MIB (P-bridge, Q-bridge), RFC2819 RMON MIB (groups 1,2,3,9 only), RFC2737 Entity MIB, RFC 2618 RADIUS Client MIB
RMON Embedded Remote Monitoring (RMON) software agent supports four RMON groups (history, statistics, alarms, and events) for enhanced traffic management, monitoring, and analysis.
Firmware Upgrade Web Browser upgrade (HTTP) and TFTP
Port Mirroring Traffic on a port can be mirrored to another port for analysis with a network analyzer or RMON probe
Other Management RFC854 Telnet (Menu-driven configuration), Secure Shell (SSH)* and Telnet Management (SSHv2), Telnet client, SSL security for Web UI, Switch audit log, DHCP client, BootP, SNTP, Xmodem upgrade, Cable diagnostics, PING
Security
IEEE 802.1x 802.1X - RADIUS Authentication.
MD5 Encryption ACLs - Drop or rate limit based on: Source and destination MAC address, Source and destination IP address, Protocol, ToS/DSCP, Port, VLAN, Ethertype
Availability
Link Aggregation Link Aggregation using IEEE 802.3ad LACP Up to 8 ports in up to 8 trunks
Storm Control Broadcast and Multicast
Spanning Tree IEEE 802.1d Spanning Tree, IEEE 802.1w Rapid Spanning Tree, IEEE 802.1s Multiple Spanning Tree, Fast Linkover
IGMP Snooping IGMP (v1/v2) snooping provides for fast client joins and leaves of multicast streams and limits bandwidth-intensive video traffic to only the requestors
QoS
Priority Levels 4 Hardware Queues
Scheduling Priority Queuing and Weighted Round Robin (WRR)
Class of Service Port-based, 802.1p VLAN priority based, IPv4/v6 IP Precedence/TOS/DSCP based, TCP/UDP port-based
Layer 2
VLAN Port-based and 802.1q based VLANs, Management VLAN
HOL Blocking Head of line blocking prevention
Jumbo frame Supports frames up to 10K byte frames
Environmental
Dimensions 17.32" x 1.75" x 13.7”
WxHxD (440 x 44 x 348 mm)
Unit Weight 8.85 lb (4.02 kg)
Power 100-240V 0.5A
Certification FCC Part15 Class A, CE Class A, UL, cUL, CE mark, CB
Operating Temperature 32 to 122ºF (0 to 45ºC)
Storage Temperature -4 to 158ºF (-20 to 70ºC)
Operating Humidity 20 to 95%
Storage Humidity 5 to 95%
Warranty 5 years

Package Contents:

  • SRW224G4P Switch
  • AC Power Cord
  • Rack Mounting Kit with Brackets and Hardware
  • CD with User Guide in PDF Format
  • Online Registration Card
  • Console Cable


Wednesday, November 24, 2010

CL400 , handheld Fiber Optic inspection scope

CL400 is a coaxial illuminated handheld fiber optic inspection scope. Fiber optic inspection microscopes are used to inspect the end face of a connector or cleaved fiber. There are two major types of fiber microscopes available; one is for fiber termination inspection and the other is for inspection of installed connectors on patch panels and hardware devices.
The typical magnification level is 200X or 400X for single mode fiber applications. with 400x magnification you can clearly see scracthing, dig, dirt deposit, debris and other contaminations.



Features:
  • CE approval
  • LED Illumination
  • vesatile adapter interface
  • clear bright image
  • smooth focus control
  • momentaru push button on/off switch
  • laser filter installed for eye protection

Specs:
  • Rubber housing , anti slip
  • optical magnification 400 times
  • power source AAA 3X battery ( not included )
  • light source: white LED rated for 100,000 hours
  • weight approx. 0.5Kg
  • size: 225X (long) 32Xmm (diameter)
  • control: momentary on/ off switch for light source , fine focus controll wheel
  • safety filter: built in IR filter
  • adapter interface: user interchangeable adapters

SRF485 Ultrasonic range finder

The SRF485 is a single transducer ultrasonic ranger, based on our original SRF02 design. The SRF485 uses the RS485 standard for communications, for up to 127 modules on each RS485 bus. The SRF485 features an on-board 5v power regulator which can be supplied from 8vdc to 14vdc. Both power and RS485 signals are supplied to the module via a 10pin IDC connector, making cabling a large number of modules very easy. The Range of the SRF485 is 30cm to 5meters.

Specification
  • Voltage - 12vdc (8vdc - 14vdc)
  • Current - 10mA
  • Range - 30cm - 5meters
  • Temperature Compensation - -30 to +50 centigrade
  • Size - 38mm x 38mm (1.5" x 1.5")
  • Mounting - 30.5mm x 30.5mm (1.2" x 1.2")
  • Transducer - 16mm dia. centrally mounted.

Tuesday, November 23, 2010

SSC-32 servo controller

The SSC-32 (serial servo controller) is a small preassembled servo controller with some big features. It has high resolution (1uS) for accurate positioning, and extremely smooth moves. The range is 0.50mS to 2.50mS for a range of about 180°. The motion control can be immediate response, speed controlled, timed motion, or a combination. A unique "Group Move" allows any combination of servos to begin and end motion at the same time, even if the servos have to move different distances. This is a very powerful feature for creating complex walking gaits for multi servo walking robots. The servo's position or movement can be Queried to provide feedback to the host computer. There is even a 12 servo Hexapod sequencer built in. This allows complete control of all aspects of the alternating tripod gait simply by transferring a few values from the host controller. Any output can be used as a TTL level output. There are 4 digital inputs that are static or latched, so you don't have to worry about missing a short event. They can also be used as analog inputs. There are three terminal blocks for powering options. The DB9 input has true RS-232 levels for use with a PC.

These specifications pertain to firmware version 2.01XE:

* Microcontroller = Atmel ATMEGA168-20PU
* EEPROM = 24LC32P (Required for 2.01GP)
* Speed = 14.75 MHz
* Internal Sequencer = 12 Servo Hexapod (Alternating Tripod)
* Serial input = True RS-232 or TTL, 2400, 9600, 38.4k, 115.2k, N81
* Outputs = 32 (Servo or TTL)
* Inputs = 4 (Static or Latching, Analog or Digital)
* Current requirements = 31mA
* PC interface = DB9F
* Microcontroller interface = Header posts
* Servo control = Up to 32 servos plug in directly
* Servo type supported = Futaba or Hitec
* Servo travel range = 180°
* Servo resolution = 1uS, .09°
* Servo speed resolution = 1uS / Second
* Servo motion control = Immediate, Timed, Speed or Synchronized.
* PC board size = 3.0" x 2.3"
* VS current capacity = 15 amps per side, 30 amps max

RXM01 ism band FSK receiver module.

RXM01 ism band FSK receiver module.

Low cost ISM Band receiver module implemented with unique PLL and zero IF design approach , and work with FSK modulation signal ranges from 315/433/868/915MHz band, comply with FCC, ETSI regulation. The SPI interface is used to communicate with microcontroller for parameter setting. RXM01 work with TXM02 transceiver module at 433MHz band. The pair of module can work up to 300 meter in open air (line of sight )

Features:
  • Low cost , high performance
  • tuning free during prduction
  • FSK reception
  • PLLand zero IF technology
  • fast PLL lock time
  • high resolution PLL with 2.5KHz step
  • high data rate up to 115.2kbps with FSK modulation)
  • differential antenna input
  • automatic antenna tuning
  • Programmable rceiver bandwidth (from 67 to 400 kHz)
  • Analog and digital signal strength indicator (ARSSI/DRSSI)
  • AFC
  • DQD
  • Internal Demodulator
  • SPI interface
  • clock and signal reset for external MCU use
  • 16 bits FIFO
  • low power mode (< 0.5 mA averaged current constumption)
  • 10MHz xtal for PLL reference
  • wakeup timer
  • 2.2V-5.4V power supply
  • low batt detection
  • low power consumption
  • standby current less than 0.3 micro Amp.

TXM02 ism band FSK transmitter module

TXM02 ism band FSK transmitter module.
Low cost ISM Band transmitter module implemented with unique PLL approach , and work with FSK modulation signal ranges from 433/868/915MHz band, comply with FCC, ETSI regulation. The SPI interface is used to communicate with microcontroller for parameter setting. TXM02 work with RXM01 receiver module at 433MHz band. The pair of module can work up to 300 meter in open air (line of sight )

Features:
  • Low cost , high performance
  • tuning free during prduction
  • FSK transmission
  • PLL employed
  • fast PLL lock time
  • high resolution PLL with 2.5KHz step
  • Programmable frequency deviation (from 30 KHz to 210 KHz, step 30 KHz)
  • programmable output power
  • high data rate up to 115.2kbps with FSK modulation)
  • differential antenna output
  • automatic antenna tuning
  • SPI interface
  • clock and signal reset for external MCU use
  • 10MHz xtal for PLL reference
  • Programmable xtal load capacitor bank
  • wakeup timer
  • low batt detection
  • low power consumption
  • standby current less than 0.3 micro Amp.

Monday, November 22, 2010

Bioloid Premium Kit

Bioloid Premium Kit
It is the upgraded and latest version of Bioloid Comprehensive Kit. (Expert Kit - Labs version of Comprehensive Kit)
Bioloid includes gyro sensor, DMS sensor, and multi-channel wireless expendable remote controller. (Based on Premium Kit) Please make sure that it is easy to insert and take out the batteries; the cables are arranged safely; it has outstanding compatibility.

Components
-CM-510 (Main Controller): 1 piece

RoboPlus is an icon-type, C language-based, and easy-to-use software for users who do not understand computer program languages. The motions and behaviors of robots can be programmed and managed with the software. The users can learn the structure and the grammar of C language eventually while using RoboPlus. In addition, various C language program examples are provided for experts.


* CPU: ATMEGA 2561
* Internal I/O Device: 6 buttons, Mic, Temperature sensor, and Voltage Sensor are included
* External I/O Device: GP I/O & 6 of 5P I/O port for analog sensor installation AX-Series Dinamixel connector: 5 pieces
* Mode Display & AUX LED

- Robot Exclusive Servo Dynamixel(AX-12+): 18 pieces
- 2-axis Gyro Sensor: 1 piece
- DMS Sensor: 1 piece
- IR sensors: 2 pieces
- RC-100(Remote Controller): 1 piece
- Skin Set for Humanoid
- Li-Po Battery (11.1V, 1000mA/PCM) : 1 piece
- Battery Charger
- USB2Dynamixel
- Quick Start Book (3-types of humanoid robot examples are provided)
- Screw Driver, Cable Holder
- RoboPlus CD

Merits
1) Excellent walking humanoid (Self-Adjusts posture while walking)
2) Various sensors including Gyro, Distance, and IR
3) RC-100(Remote Controller) is included (IR-default, Zigbee-optional)
4) C-style programming & motion teaching with RoboPlus S/W (USB interface included)
5) Semitransparent humanoid skin for customization
6) Digital packet communication with daisy chain topology
7) Build various robots through versatile expansion mechanism

Comparison table:
Description Bioloid Beginner Kit Bioloid Comprehensive Kit Bioloid Premium Kit
Web Links Web Link another Web Link
Main Controller CM-5 CM-5 CM-510
DYNAMIXEL
(servomotor)
AX-12+ : 4EA AX-12+ : 18EA AX-12+ : 18EA
Sensor AX-S1 AX-S1 GYRO, DMS, IR
S/W BIOLOID SOFTWARE BIOLOID SOFTWARE RoboPlus
Power Eneloop Ni-MH 9.6V
SMPS 12V 5A
Eneloop Ni-MH 9.6V
SMPS 12V 5A
Li-Po 11.1V
SMPS 12V 5A
Remote Control RC-100 +
ZIG-100 set (Option)
RC-100 +
ZIG-100 set (Option)
RC-100
ZIG-110 set (Option)
Manual Quick Start (14 robots)
User's Guide
Quick Start (26 robots)
User's Guide
Quick Start (3 robots)
e-manual (26 robots)
Usage Education(School) Education(School/Univ.)
Entertainment/Hobby
Education(School/Univ.)
Competition/Entertainment
/Hobby
