20X2 large character LCD with backlight


20X2 large character LCD with backlight

This is a 20 character x 2 line blue HD44780 Super Twisted Nematic (STN) LCD with built-in HD44780 equivalent controller (also known as alphanumeric displays).

Interfacing is simplified with 4 bit or 8 bit communications and programming code is widely available for many different controllers and systems. Perfect companion for your project, whether you are using an Arduino, ATMEL AVR or PIC microcontroller.

Includes LED backlight.



specifications:
- Power supply: 4.5 V (min)
- Interface: Parallel
- Number of lines: 2
- Number of columns: 20
- LCD Type: STN, Positive, Transflective, Yellow Green
- Backlight: LED yellow green
- Controller: HD44780 / type
- View area: 149.0 x 23.0 mm
- Dimensions: 180.0 x 40.0 x 13.9 mm
