1 Pin Female-Male Jumper Wire 125mm

1 Pin Female-Male Jumper Wire 125mm (50pcs pack)
  • 1-pin jumper cable Male-Male with a length of 125 mm.
  • In 1 pack contains 50 pcs cables.
  • Red, yellow, blue, white and black
  • Cable Type Fiber + pin
  • length 125mm

MSR-H01-PTH Pan & Tilt kit for MSR-H01

Is a complementary accessory kit (head) for Hexapod robot.
His plate is made of acrylic material with a thickness of 3mm.
In the sales package does not include servo.

This kit fits with servo:
HS-225BB and HS-322HD.

4 channel controller for Rover 5

4 channel controller for the Rover 5 is a module that is used to control a DC motor. This module can be used to control up to 4 DC motors. This module is also equipped with current sensors on each channel so that the microcontroller can receive feedback from each motor. In addition this module has a range of encoder that can combine 2 encoder inputs to 1 output signal (encoder mixing circuit).

features:
- 4 pieces of low resistance FET ?? H ?? bridges.
- Each channel has a rated current of 4A.
- Control logic is simple.
- Monitoring currents for each channel.
- A range of mixing quadrature encoder.
specifications:
- Power connector: 2 connector (5 VDC for logic, 12V (max) for motor)
- Sensor Flow: has a 1V output for each Ampere current consumed by the motor (maximum output 5VDC)
- Control Logic: 1 pin for direction (the direction of rotary motor) and one pin for PWM (motor speed)
- Power supply motors: 4.5V-12V DC with a current of less than 4.5A

Toggle Switch 6 pin

6 pin toggle switch (250V / 2A).

  • Pin number 6 pin (3x2)
  • configuration DPDT
  • Type Toggle Switch
  • Logic On - Off
  • Voltage / Flow max 250V / 2A

25LC640-I/P 64Kbit EEprom

25LC640-I/P DIP8 (e3xPb)

  • 64 Kbit serial EEPROM Memory accessed through SPI.
  • Power supply 2,5V - 5.5 V.
  • 8-pin DIP packaging
  • SPI interface
  • Capacity of 64 Kbit

IL300 optocoupler

A linear optocoupler containing AlGaAs IRLED and PIN photodiode output.

Features:
- Couple AC and DC signals.
- Linear servo 0.01%.
- Wide Bandwidth:> 200 kHz
- Stability of high gain: ± 0.005% / ° C
- Capacitance input-output low.
- Low power consumption, <15 mw.="" p="">

GPS module LR9540 with LR9130P

A receiver module (receiver) GPS. Where this module has a high-performance, power efficient and has 20 channels of TTL level GPS.
Is suitable for applications such as:
- Setting a means of transportation.
- AVL (Automatic Vehicle Locator) or search the vehicle's position automatically.

Tech Spech:

  • Power supply 3.3 to 5 (Vdc)
  • Working frequency L1, 1575.42 MHz
  • controller LR9130P
  • Positioning accuracy 10m 2D RMS | 5m 2D RMS, WAAS corrected
  • Accuracy speed of 0.1 meters / second
  • Number 20 channel satellite reception
  • Hot start 1 sec
  • Warm start 35 sec
  • Cold start 35 seconds
  • Interface DIP, 2 x 10 pin header
  • Antenna (internal / external) external

Wednesday, July 27, 2016

Twist Tie 50M + Cutter

Colored cable tie to secure the cable with a length of 50 m is equipped with a cutter.
available color option: red, green yellow black.

GWS Servo S03T/2BB/F

Standard type servo motor production GWS which has a large torque and is equipped with 2 ball bearing


  • Dimensions 1.56 x 0.79 x 1.56 in
  • The working voltage 4.8 - 6 VDC
  • The maximum rotary speed of 0.27 sec / 60 ° @ 6V,
  • Standard round types
  • PWM control mode
  • The maximum torque 7,2kg.cm @ 4,8V
  • Weight 46 grams

Monday, July 25, 2016

3.7V 750mAh LIPO Battery

Lithium Polymer rechargeable cell with a protection circuit.

  • Voltage 3.7 VDC
  • rechargeable Yes
  • Capacity of 750 mAh
  • Battery type Lithium Polymer (LiPo)

LIPO BATTERY HAIYIN 7.4V 1000MAH 2S 20C

LIPO BATTERY HAIYIN 7.4V 1000MAH 2S 20C
Battery Li-Po (Lithium Polymer) with a capacity of 1000mAh 7.4VDC. The battery has a 2S1P configuration and has a rate of 20C for discharge.

  • Dimensions: 72 x 36 x 14 mm
  • Voltage 7.4 VDC
  • Rechargable Yes, max charge rate 1.5C, charging current max 1.5A
  • Capacity 1000 mAh
  • Battery type Lithium Polymer (LiPo)

NCS6S1205C Isolated DC/DC Converters 6W 12Vin 5Vout 1.2A

NCS6S1205C Isolated DC/DC Converters 6W 12Vin 5Vout 1.2A

6W Single Output DC-DC Converter series production NCS6 Murata Power Solutions are packed with metal. Suitable for telecom applications, battery-powered systems and other power system applications.

Specification:
- Single output
- Input voltage: 9-36 VDC (typ. 12 VDC)
- Output voltage: 5 VDC
- Output current: 1.2 A
- Power output: 6 W
- Insulation Voltage: 1.5 KVDC

0.96 inch OLED Module 128x64 for Arduino

OLED module 0.96 inches with a resolution of 128x64 pixel display that can be used on the module Arduino or other microcontroller. Based SSD1306 chip which has I2C and SPI interface thereby minimizing the use of the number of I / O ports of the microcontroller. OLED modules can be used for display applications such as mobile phones, MP3 / MP4, digital camera, etc.
* This module is not supported for use on a mainboard with 5 VDC voltage level.

Specification:
- Power Supply: 1.65 - 3.3 VDC (typ. 3.3 VDC)
- Interface: I2C (default), SPI
- Screen resolution: 128 x 64
- Dimensions: 35.5 x 35.5 x 1.6 mm

1.3inch OLED Module 128x64 (B)

1.3inch OLED 128x64 Module (B)
OLED module with a screen resolution of 128x64.

Specification:
- Driver chip: SH106
- Resolution: 128 x 64
- Screen size: 1.3 inch
- Interface: 3-wire SPI, 4-wire SPI, I2C
- Blue
- Viewpoint:> 160 °
- Dimensions: 40.5 x 37.5 mm

Thursday, July 21, 2016

0.96inch OLED Module 128X64 (B)

A module measuring 0.96 inch OLED display with a vertical pin-header (model B).
This module has been equipped with I²C interface, 3-wire and 4-wire SPI SPI.

  • Power supply 3.3V - 5V
  • Dimensions 33 x 33.5 (mm)
  • Dot number 128 x 64
  • Color Light Yellow, Blue
  • Display mode (passive / active) Passive matrix

Wednesday, July 20, 2016

8GB eMMC5.0 Module for Odroid XU4 Linux

Manifold memory module eMMC version 5.0 for mini PC Odroid Xu3 / Xu4 with a capacity of 8 GB.
The major advantage eMMC 5.0 is the speed that can achieve 7x faster than microSD Class 10.

In the sales package includes:
- EMMC microSD Reader (eMMC converter to microSD).
- Pre-installed Ubuntu 15:04 or later.

Speed Comparison:

  • microSD Class 10: Writing 8.5 MB / s - Reading 18.9 MB / s.
  • SD-UHS1: Writing 10.8 MB / s - reading of 35.9 MB / s.
  • eMMC 5.0: Writing of 39.3 MB / s - Read 140 MB / s.

AT62 433 MHz Antenna

433 MHz Antenna AT62 ( Tyoe: 0433AT62A0020E)
This antenna made from ceramics and has been using the technology of LTCC (Low Temperature cofired ceramic), where the technology has the ability to stabilize the low and high dielectric that is in the antenna. Additionally, this antenna also easy tuning.
Features:
- Extreme temperature stability: Up to 2ppm.
- Peak typical and strengthening Average: -4dBi
- Working temperature: -40 ° C to + 85 ° C
Working frequency 433 MHz
The input impedance of 50 Ohm
-4 DBi gain (typical)

Monday, July 18, 2016

Chip DS1802+

Integrated Ciruit with a dual audio taper digital potentiometers.

Features:
- Resistance: 45 kOhm.
- Temperature Coefficient: 750 PPM / ° C
- Tolerance: 20%
- Number of POT: Dual.
- Tap per POT: 65.
- Interface: Serial (3 wires).
- Working Voltage: 2,7V - 5.5 V.
- Workflow: 2000 uA
- Packaging: PDIP - 20 pin

OV2640 Camera Board 2 Mpx

OV2640 Camera Board 2 Mpx
Features

  • 2 Megapixel
  • Array size: UXGA 1622X1200
  • Power supply: 3.3V
  • IO voltage level: 1.7V~3.3V DC
  • Output formats:
  • YUV(422/420)/YCnCr422
  • RGB565/555
  • 8-bit compressed data
  • Max image transfer rate:
  • UXGA/SXGA 15fps
  • UXGA/SXGA 30fps
  • SVGA 30fps
  • CIF 60fps

SparkFun Photon RedBoard

 The SparkFun Photon RedBoard, to put it simply, is a WiFi/Microcontroller development board in the Arduino form-factor for the Photon. It’s easy to use, it’s powerful, and it’s connected to the cloud. With the best support, potential, and performance the Photon RedBoard provides you with an IoT device with a powerful 120MHz ARM Cortex M3 and built-in WiFi connectivity. Imagine blowing up a Photon into the shape of an Arduino and while keeping its wireless and ARM Cortex M3 capabilities, the result is this board!

The SparkFun Photon RedBoard has been based around the P1 Particle Module. Each P1 comes pre-loaded with Particle OS firmware and includes their basic cloud service. With a built-in antenna and a uFL connector, the P1 makes it so you don’t have to stress over the optimization of RF designs.

The Photon RedBoard has all of the hardware peripherals you know and love: 8 Digital I/O pins, 6 Analog Inputs, UART, SPI and ARM JTAG hook-ups. We’ve also broken out the SDA, SCL, SCK, MISO, MOSI, SS, DAC, and WKP pins as well. You can power the Photon RedBoard over USB or through the barrel jack. The on-board power regulator can handle anything from 4.5 to 15VDC. It is important to keep in mind that the Photon RedBoard utilizes the Arduino form factor, meaning you can attach many different Arduino shields to this board. Please be sure to check your pin-outs and voltage levels first.

Features:
  • STM32F205 120MHz ARM Cortex M3
  • 1MB flash, 128KB RAM
  • Single band 2.4GHz IEEE 802.11b/g/n
  • Supports wireless data rates of up to 65Mbit/s
  • Ultra low power sleep, stand-by and stop modes
  • Supports Open, WEP, WAPI, WPA and WPA2-PSK WiFi security modes
  • Input voltage - 4.5-15V
  • 8 Digital I/O Pins
  • 6 Analog Inputs
  • ARM JTAG Hook-up
  • Arduino Form Factor

LilyPad Design Kit

The LilyPad Design Kit (LDK) is a great way to get started with e-textiles. The LDK includes everything you need to complete 6 simple experiments that will teach you how to sew basic circuits, light LEDs, create interactive designs, and more. You don’t need any previous sewing or electronics experience to use this kit. If you’ve ever been curious about getting into e-textiles but have never known where to start, this is where you can begin!

The online LDK Tutorial contains step by step instructions of how to connect each circuit with the included parts. Tips and tricks are provided and explained and even includes troubleshooting tips if something goes wrong. A link to this tutorial can be found in the Documents section below. The kit does not require any soldering and is recommended for beginners of any age that can can hold a needle.

LilyPad is a wearable technology developed by Leah Buechley and cooperatively designed by Leah and SparkFun. Each LilyPad was creatively designed to have large connecting pads to allow them to be sewn into clothing. Various input, output, power, and sensor boards are available. They’re even washable!

Note: A portion of this sale is given back to Dr. Leah Buechley for continued development and education of e-textiles.

Note: Due to the requirements of shipping the batteries in this kit, orders may take longer to process and therefore do not qualify for same-day shipping. Additionally, these batteries can not be shipped via Ground or Economy methods to Alaska or Hawaii. Sorry for any inconvenience this may cause.

LDK Experiments:

  • Experiment 1: Lighting a Basic Circuit
  • Experiment 2: Multiple LED Circuits
  • Experiment 3: Buttons and Switches
  • Experiment 4: Make Your Own Button
  • Experiment 5: Make your Own Switch
  • Experiment 6: Microcontroller Circuits

Kit Includes:

  • 1x LilyPad Parts Box
  • 1x Felt Sheet - 9" x 12"
  • 1x Conductive Fabric - 6" x 6.5" Ripstop
  • 1x Needle Set
  • 3x Conductive Thread Bobbin - 30ft (Stainless Steel)
  • 4x SimpleSnap (2 Male, 2 Female)
  • 7x Coin Cell Battery - 20mm (CR2032)
  • 1x LilyTiny
  • 1x LilyPad Slide Switch
  • 1x LilyPad Button Board
  • 2x LilyPad Rainbow Led Strip
  • 3x LilyPad Coin Cell Battery Holder - Switched - 20mm
  • 4x Lilypad Coin Cell Battery Holder - 20mm

ATF-55143-TR1G Transistor

An RF-FET transistor that has a great reinforcement, high linearity and low distortion so that the components are widely used on mobile devices and wireless data system.
  • The system works on a frequency of 450 MHz to 6 GHz.
  • Packaging SOT-343 (4-pin)
  • Power dissipation is 270 mW
  • Drain-source voltage VDS 5V
  • Gate-source voltage of 0.47 V
  • Continuous drain current of 100 mA

1N5223B (Zener 2.7V, 500mW)

2,7V Zener diode voltage and power dissipation of 500mW.

  • Packaging do-35
  • voltage 2,7V
  • Power 500 mW

Chip 74HCT14D

IC is a hex inverting Schmitt trigger in a 14 pin SOIC packaging.
The power supply 4,5VDC - 5,5VDC
Packaging Dip 14 pin
Function Hex Schmitt-Trigger Inverters
Propagation delay is 43-51 (ns)
Voltage level i / o TTL

48MM OMNI WHEEL FOR LEGO NXT/SERVO MOTOR/DC motor

Omni Wheel or wheels that can rotate in all directions with a diameter of 48mm. This wheel is equipped with 2 different hubs that have holes on each hub. This wheel can be used on LEGO NXT, servo and DC gear motor.

Specification:
- Wheel Diameter: 48 mm
- Roller Diameter: 13 mm
- Material: Nylon
- Load capacity: 2 kg (max.)

Crystal 2MHz (MEC)

Crystal components with the working frequency of 2 MHz (2000 MHz).

CERAMIC Capacitor 22UF/25V/10 %

CAP CERAMIC 22uF / 25V / 10% / 1210 (GRM32EC81E226KE15L). SMD ceramic capacitors with multilayer packaging.

  • Capacitance of 22 μF
  • voltage 25VDC
  • Tolerance 10%

Li-Po Battery 500mAh 3.7V

Lithium-Polymer battery that can be recharged with a capacity of 500 mAh.

Features:
- Temperature charging: 0 ° C - 45 ° C
- Length of charging: ± up to 5 hours.
- Completion of the standard: 0,2c
voltage 3.7 V
rechargable Yes
Capacity of 500 mAh
Battery type Lithium Polymer (LiPo)

Aluminium Electrolytic Capacitor 220uF 35V SMD 8x10mm

Aluminum Electrolytic Capacitor 220uF 35V SMD 8x10mm (500pcs / Reel) (Nichicon)

  • capacitance 220uF
  • voltage 35V

Aluminium Electrolytic Capacitor 100uF 25V SMD 6.3x7.7mm

Aluminum Electrolytic Capacitors SMD / SMT 100uF capacitance value and has a voltage rating 25V.
- Dimensions: 6.3x7.7mm
- 900pcs / reel
capacitance 100uF
voltage 25V
Tolerance 20%

Aluminium Electrolytic Capacitor 47uF 50V SMD 8x10mm

Aluminum Electrolytic Capacitors SMD / SMT with a capacitance value of 47uF and has a voltage rating 50V.

- Dimensions: 8x10 mm
- 500pcs / reel
- Capacitance 47 uF
- Voltage 50 V
- Tolerance 20%

Switching Adapter 5V 2.5A Micro Port USB Charger

Switching adapter 5V / 2,5A with Micro USB connector that can be used for power supply Raspberry Pi.

Specification:
Input: 100-240 VAC @ 50 / 60Hz
Output: 5 VDC / 2.5 A
Plug type: Micro USB
Cable length: 1 M

2 Channels 5V Relay Module

This is a 5V 2-Channels Relay module, It can be controlled directly by a wide range of microcontrollers such as Arduino, AVR, PIC, ARM and MSP430. 2 relays are included in this module, with “NC” ports means “Normally connected to COM” and “NO”

Features
  • 2 mechanical relays with status indicator LED
  • Both “NC” and “NO” ports for each relay


Sunday, July 17, 2016

DYNAMIXEL PRO H54-200-S500-R

An actuator that has been integrated with the reduction gear system, controller, driver and network to build a modular robot.
Control of current, speed and position have been using algorithms.
Torque used to control the flow sensor, while the PID control is used to determine the position of the robot.


  • Has a resolution of 501 900 steps / revolution (very precise).
  • To use RS-485 communications.
  • Working voltage 24V
  • Current consumption without load 1.65 A
  • The current consumption of 9.3 A
  • Maksumum torque of 44.7 Nm (6,330 ofz.in)
  • The maximum rotary speed of 33.1 rpm (no load)
  • Comparison gear box 502: 1

Li-ion Battery 3.7V 1300mAh LB-040

Lithium-ion rechargeable battery from Robotis that can be used on robotic MINI or other projects that use the CM-150 controller and OpenCM9.04.
features:
- PCM built-in to protect the battery from overcharge, discharge and overcurrent.
- To avoid damage to the battery, try to wait for the battery to cool before charging.
- Accompanied by a protective cover of the battery.
- Dimensions: 24 x 70 x 27mm
- Charger: Li-ion Battery Charger Set LBB-040 (sold separately)

Preventive measure:
- Do not charge the battery when connected to the robot / controller.
- Remove and store the battery in a cool / dry when not in use.
- For long-term storage can deduct advance up to 50% of the total battery capacity.

Voltage 3.7 VDC
rechargable Yes
Capacity 1300 mAh
Type Lithium-ion battery

Li-ion Battery Charger Set LBB-040

Charger is designed for Li-ion Battery 1300mAh 3.7V LB-040 from Robotis. Frame the charger is compatible with Robotis OLLO MINI and kits from Robotis.

features:
- There is a charging indicator: Red Led (charging), Led Off (charging complete)
- Package sales: 1x Li-ion Battery Charger Set LBB-040, 1x USB Micro B Cable, 1x Robot Cable-2P for Battery Box (100mm).

* Try not to charge the battery when connected to the robot / controller.

Power supply 5V DC (from USB)
There are features LED battery charging indicator
Compatible to the type of battery Li-ion Battery 1300mAh 3.7V LB-040
Compatible to the size of the Li-ion Battery 1300mAh 3.7V LB-040

3.2inch 320x240 Touch LCD ( C )

It is a touch screen with a size of 3.2 inches and a resolution of 320 x 240. It also has to have its own controller.
  • Power supply 3.3V / 5V
  • Dimensions 94.97 x 62.24 (mm)
  • Number of 320 x 240 dot
  • SPI interface
  • Type TFT lcd
  • LED backlight
  • Controller ILI9325 | Touch Screen Controller: XPT2046

OV7670 Camera Board 0.3 Megapixel (B)

The OV7670 is a camera with a CMOS sensor and requires only a small voltage. Where this camera also has a relatively small size so it is suitable for applications such as toys, multimedia PCs and more.
In addition, users can also make arrangements such as image quality, image format and output data transfer.

Some of its features:
- Quite sensitive to low light conditions.
- Supports image sizes: VGA, CIF and CIF all scale sizes ranging down to 40 x 30.
- Using VarioPixel® method for sub-sampling.

Magnetic Stripe (icebo accessories)

These accessories are a complementary tool iClebo floor cleaning robot. Shaped like plaster and containing magnets.
The function of the magnetic tape is to limit a space that can not be entered automatically by robot floor cleaners iClebo.
Its use simply by attaching this tape on the floor in front of the room who did not want to be penetrated by iClebo.

G1/2 Electric Solenoid Valve

An electrical solenoid with the condition of NO (Normally Open).
Suitable for projects related to the control of liquids with low fiskositas.

Features:
- The size of inlet port / outlet: G1 / 2 "
- Material: Nylon / stainless steel / Polyoxymethylene.
- The type of valve: diaphragm (driven by servo).
- The maximum working temperature: 120 ° C.
- Range of pressure: 0.02 to 0.8 (MPa).
- Filter screen: Stainless steel inlet filter.

Current Flow 450 mA (max)
12VDC power supply
This mode of operation Normally Open (NO)

Saturday, July 16, 2016

DHT11 Temperature and Humidity Sensor

DHT11 digital sensor module is capable of detecting the temperature and humidity. The readings can be directly read by the microcontroller via the 1-wire interface.

specifications:
- Power Supply: 3VDC - 5,5VDC
- Interface: 1-wire
- Range: humidity = 20-90% RH, Temp = 0-50 degrees Celsius
- Resolution: 1% RH (humidity) and 0,1C (temp)
- Already available complementary circuit ring, and so can be directly connected to the microcontroller.
- Dimensions: 12 x 15.5 x 5.5 mm

Tuesday, July 12, 2016

Hubsan FPV X4 Mini QuadCopter

Hubsan X4 Mini Quadcopter FPV has been using the technology system 6-axis flight control most recently,
In addition, the controller section has also been equipped with an LCD screen measuring 4.3 inch for the purposes of direct observation (live streaming).
Copter for battery charging can be through USB ports on the computer and only takes 30 minutes to be filled.
Copter can perform low for 7 minutes.

specifications:
- Motor: Coreless 0820 4x.
- Transmitter: 2.4GHz + 5.8 GHz (for videos).
- Distance control: 50-100 meters.
- Reach live video: ± 100 meters.
- Battery: Li-Po 3.7 V, 380mAh with auto cut off safety PCB.
- Length of charging: ± 30 minutes.
- Length of flight: ± 7 minutes.
- Camera: 0.3M pixel resolution of 640 x 480.
- There is a microSD slot on the controller for the purpose of video recording.
- There are 4 LED lights for night and rubber on the legs copter.

Wednesday, July 06, 2016

Hubsan Q4 Nano QuadCopter

Hubsan NANO Q4 H111 45mm/ 11.5g Quad Copter 4-Channel RC Quadcopter with 2.4Ghz Radio System


Hubsan Q4 Nano quadcopter. This lightweight, easy to fly Nano quad comes ready-to-fly straight from the box, it may be small but its performance capabilities belie its size with it even being able to fly outdoors, wind conditions dependant. One year under development, the Hubsan Q4 is the ultimate in micro RC technology. Stylishly designed, with equally impressive performance it promises to be the absolute must have gadget for 2014 and beyond. Just add 2 x AAA batteries to the transmitter and you are ready to fly in literally any space available. Q4 Nano Quadcopter Features: Ultra small design, LED Lights for front and back flying guide and low light flying, 4-Channel 2.4ghz Radio with digital trim, Integrated gyro for stable flying, 100mAh 3.7v Lipo battery, Spare blades included, Weighs 11.5grams, USB Charge cord, Coreless micro motors. Spec: Dimensions: 45 mm x 45 mm, Weight: 11.5 grams, Requires: Two AAA batteries, Charge Time: 10 minutes

Box Contains
1*q4 Quadcopter 1*USB charger 1*Controller Spare blades

Avitron V2.0 R/C Ornithopter

 Spread Spectrum 2.4 GHz Radio control
• Both indoor and outdoor use
• Easy control
• Multi-frequency - 128 players at same time

My Bionic Bird introduces the My Bionic Bird Avitron v2.0 R/C Ornithopter. A bird is not an airplane and does not use the same principles to get around. After watching how real birds perform, manufacturer developed and patented a control system that uses wing bending, enabling fast and instantaneous maneuvers that are not possible with a classical drift system. Thanks to this system, coupled with its adjustable tail effect, that you can even fly it around your sitting room. The amazing range of the radio control (100 m) with its laboratory optimized aerial lets you follow the birds into the clouds. Charging time is only 12 minutes for 8 min flight time.

Features:
• Ultra-compact structure
• Centrally aligned "vertebral column"
• Battery has been developed to an outstanding quality
• Unconventional materials have been used to maintain performance

Friday, July 01, 2016

USB to TTL 4-pin Wire

USB to TTL 4-pin Wire
specification:

  • Embedded convertor: PL2303
  • Supports Win8
  • Connector: USB Type-A plug, 4-pin 2.54mm jumper wire connectors
  • Jumper wire pinout:
  • Red - VCC
  • Black - GND
  • Green - TXD
  • White - RXD
  • Length: 1m

HDMI Male to DVI-D Male Cable 1.5m

Display cable using the connector of the HDMI Male and DVI-D.
Cable length of 1.5 m.

Capacitive Touch Keypad (B)

  • Onboard 8 capacitive touchkeys and 1 linear capacitive touch sensor
  • Features TONTEK TonTouch touch pad detector IC TTP229-LSF, supports up to 16 keys with adjustable sensitivity and built-in LDO
  • The system re-calibrates automatically when all keys are not detected touch more than about 4 seconds
  • Configurable functions:
  • 8 keys OR 16 keys option
  • 8 separate outputs OR serial output
  • single-key OR multi-kye feature
  • Sampling rate and sampling length at sleep mode
  • Maximum key-on time

Specifications

  • Interface : I2C OR I/Os
  • Keys : 8/16
  • Sampling rate : 8Hz/64Hz
  • Human Body Mode : 6KV
  • Operating voltage : 2.4V-5.5V
  • Operating temperature : -40℃ to +85℃
  • Storage temperature : -50℃ to +125℃
  • Dimensions : 4.7CM × 6.8CM
  • Mounting holes size : 3 × 3MM

How to Use

After power-on have about 0.5sec stable-time. During the time do not touch the key pad, and all functions are disabled
16 keys mode : short all the onboard jumpers, output via serial port, and the linear touch sensor is enabled
8 keys mode : short the SLWPTM and WPSCT, open all the other jumpers, output via OUT0-OUT7
Applications

  • Consumer Products
  • Mechanical Switch/Button Replacement
  • Photos

7 inch Capacitive Touch LCD (D)

7 inch 1024*600 Multicolor Graphic LCD, with capacitive touch screen and stand-alone touch controller
Key Parameters

  • LCD Type TFT
  • Interface RGB/LVDS
  • Touch Controller FT5206GE1
  • Touch Panel Type Capacitive (5 multi-touch)
  • Backlight LED
  • Display Size (mm) 153.6 (W) × 90.0 (H)
  • Dot Pitch (mm) 0.05 (W) × 0.15 (H)
  • Aspect Ratio 8 : 5
  • Resolution 1024 × 3(RGB) x 600 (Pixel)
  • Power Consumption TBD
  • Backlight Current TBD
  • Operating Temp. (℃) 0 ~ +70
