Tuesday, January 31, 2017

30Pin FPC Connector pitch 0.5MM right-angle SMD Bottom Contacts

FPC connector 30 positions with the type of right angle mounting.


flat cable (FFC / FPC) type-A pin 40 with a length of 152 mm and a pitch of 0.5 mm.

Relay 24V and cable

SPDT relays with 24 VDC coil voltage, contact current 30 A, and has come with a cable that can facilitate the users in applying this relay into a device. These relays are ideal for applications in industrial control systems and automotive manufacturing.

Murata NFE61PT472C1H9L (EMI Network Filter 4700PF, 50V, 2.0A)

NFE61PT472C1H9L is an artificial filter EMI Murata Power Solution with a capacitance of 4700 pF. NFE61PT472C1H9L typically used in power supply circuit to reduce a decrease in performance due to the effects of electromagnetic interference (EMI).

- Capacitance: 4700 pF
- Working voltage: 50 V
- Tolerance: - 20%, + 80%
- Workflow: 2 A
- Working temperature: -40 ° C - 85 ° C
- Dimensions: 6.8 x 1.6 x 1.6 mm
- Insulation resistance: 1000 mOhms
- Packaging: 2606

Raspberry Pi IR-Cut Camera

The camera module is optimized to work on day and night and has been fully compatible with Raspberry Pi mini PC. The camera module using OV5647 sensor resolution of 5 mega pixels and has features that can minimize the distortion of light during the day as well as an infrared LED board which serves to sharpen sensing camera at night.

- Sensor: OV5647
- Resolution: 5 MP
- CCD Size: 1/4 inch
- Aperatur: 1.8
- Focal Length: 3.6 mm
- Point of View: 75.7 degrees
- Dimensions: 31 x 32 x 10 mm
- Weight: 34.8 g

Friday, January 27, 2017

74HC164A-SMD chip

74HC164A is an 8-bit shift register that has a type of serial input and parallel output. 74HC164A is equipped with two serial data input (DSA and DSB) and eight parallel data output (Q0 - Q7).

LM358ADT chip type SOIC

LM358ADT an IC operational amplifier (Op-Amp) 2 channel that is capable of working at a maximum voltage of 30 V. This LM358ADT have disapasi power of 500 mW with a voltage gain of 100 dB. LM358ADT

4N25S-M chip

4N25S-M is an optocoupler which is the result of a combination of gallium arsenide infrared diode with a phototransistor. 4N25S-M is capable of producing isolation voltage of 7500 Vrms and disapasi power of 150 mW. 4N25S-M is commonly used in power supply regulator, input microprocessors, digital logic inputs, and so forth.

H21A3 phototransistor

H21A3 is a phototransistor that it contains an infrared diode phothotransistor gallium arsenide and silicon. Packaging on the phototransistor is also designed in a way to optimize the mechanical resolution, coupling efficiency, and rejection of light.

- Sensing Range: 3 mm
- Sensing Method: Transmissive
- Output Configuration: Phototransistor
- Forward Voltage: 1.7 V
- Forward Flow: 50 mA
- Flow Collectors: 20 mA
- Collector-emitter breakdown voltage: 30 V
- Response Time: 8-150 uS
- Working temperature: -55 ° C - 100 ° C

Thursday, January 26, 2017

ISD-DEMO2100-S Demo Kit for ISD2130

Module voice recording and playback of Nuvoton. This module is used to try capabilities of the chip ISD2130.
- Power Supply: 2.7 - 3.3 VDC
- Based chip: ISD2130
- The duration of voice recording time: 30 seconds
- Interface: SPI
- 5x2 header for connection between modules with controllers
- Has a 3.5mm audio connector and 2 pin header for the output speaker
- Has 6 pieces and 1 push button connected to GPIO header

SFH 213 FA

SFH 213 FA is artificial Osram Semiconductor photodiode with a wavelength of 900 nm. The photodiode is ideal for industrial electronics applications, photo-interupter high speed, and control electronic circuits.

Switch Slide DPDT L1.0mm SMD

Is a slide switch that is packed using SMD mounting type. The switch is capable of flowing a current of 300 mA at working voltage 4 VDC. The switch is able to hold up to 10,000 times the duty cycle, so it is suitable when applied as a switch on devices that require high durability.

MCP1640BT-I/CHY chip

MCP1640BT-I / CHY a switching regulator IC which serves to convert the voltage between 0.8 - 5.5 V to 2 V. The voltage regulator voltage has a switching frequency of 500 kHz and is usually applied in GPS devices, medical equipment, devices and other battery bertenagakan.

Siglent SPD-3303S Hi-Quality DC Power Supply

Siglent SPD-3303S DC Power Supply TFT-LCD Display  480x272 High Resolution,

Product Features

  • Support panel timing programming and output
  • 4.3" TFT-LCD display with 480x272 high resolution
  • Smart temperature controlled fan, effectively reduce the noise
  • Clear pictorialization interface, with waveform display function
  • Connect PC with USB standard interface, support SCPI commend for control and communication
  • Separate control and independent triple outputs: 30V/3A*2, 2.5V/3.3V/5V/3A*1, total 195W power
  • 5 digits voltage and 4 digits current display, min resolution: 1mV, 1mA
  • Three output modes: independent, series and parallel connect; support timing output, waveform display and SCPI remote command
  • 4.3 inches TFT-LCD display with 480*272 high-resolution
  • 100V/120V/220V/230V compatible design, to meet the need of different grid
Features and Benefits:
  • Separate control and independent triple outputs:
  • 30V/3A*2, 2.5V/3.3V/5V/3A*1, total 195W power
  • 5 digits voltage and 4 digits current display, min resolution: 1mV, 1mA
  • Three output modes: independent, series and parallel
  • connect 4.3 inches TFT-LCD display with 480*272 high-resolution
  • 100V/120V/220V/230V
  • compatible design, to meet the need of different grid Smart temperature controlled fan, effectively reduce the noise Save/Recall
  • 5 group system specifications, support data storage expansion
  • Application: R&D lab general purpose testing Teaching lab experiment Automotive electronic test Production testing and quality assessment inspection

  • Model:SPD3303S
  • Channels DC voltage range: DC voltage range: DC voltage range: Max output power:195W Min voltage/current resolution: 1mV 1mA
  • Voltage/Current display digits:4.3 inches TFT-LCD 480*272,
  • 5 digits voltage and 4 digits current display Ripple noise: 1MHz 3mArms
  • Standard interface: USB
  • Device Dimension:210mm(W) × 130mm(H) × 265mm(D)
  • Weight:7kg.

Monday, January 23, 2017

Grove Indoor Environment Kit for Intel® Edison

Grove Indoor Environment Kit for Intel® Edison makes it easy to create complete indoor environment applications with Intel Edison and Arduino Breakout Board. With the Base shield V2, developers can plug up to 11 different Grove sensors and actuators quickly. We provide cool demo codes which are constantly updated, so as to make it simple to operate even without any programming experience.

Base Shield V2 x 1
Grove - LCD RGB Backlight x 1
Grove – Temperature & Humidity Sensor x 1
Grove - Relay x 1
Grove - Moisture Sensor x 1
Grove - Servo x 1
Grove - Light Sensor x 1
Grove - Buzzer x 1
Grove - UV Sensor x 1
9V to Barrel Jack Adapter x 1
Grove - PIR Motion Sensor x 1
26AWG Grove Cables x 2
Grove - Encoder x 1
USB Cable x 1
Grove - Button x 1
User Guide x 1


Project 1: Light Control Switch

How does it work?

When the illumination<300, the servo will drive the switch. Just connect to PC, open the Serial Monitor and type the command “set light<300, servo=90”, then click “Send” button.

Part list:
Grove - Light Sensor, Grove – Servo, 26AWG Grove Cables

Project 2: Infrared Lamp

How does it work?

Connect to PC, open the Serial Monitor and type the command “set pir=1, relay=1”, then click “Send” button. Then turn on the power, the PIR Motion Sensor will lighten the lamp when it feels body motions or people passing by.

Part list:
Grove - PIR Motion Sensor, Grove – Relay, 26AWG Grove Cable

Project 3: UV Alarm

How does it work?

The buzzer will alarm when UV goes beyond 55. Connect to your PC, open the Serial Monitor and type the command “set uv>55, buzzer=1”, then click “Send” button.

Part list:
Grove - UV Sensor, Grove – Buzzer, 26AWG Grove Cable

and many more project....

MPS-845 Pushbutton Switch Lock

Pushbutton with lock function when pressed.

XR2211 chip

Monolithic phase-locked loop (PLL) for data communication.
Technical specifications:
- Working voltage: 4,5V - 20V.
- Range frequency: 0.01 Hz - 300 kHz.
- Can be connected to pin logic family DTL / TTL / ECL.
- FSK demodulation with carrier detector.
- 2 mVRMS - 3 Vrms dynamic range.
- ± 1% - ± 80% tracking range.
- Temperature drift: 20 ppm / ° C (typ)

HF3FD/012-ZS3 Relay SPDT 12V 10A

relay 12V
- Coil voltage: 12V
- Flow coil: -
- Contact Voltage: 250VAC
- Flow contact: 10A
- The number of pins: 5-pin
- Configuration: SPDT
- Dimensions: 19mm x 15,5mm x 15,2mm

Friday, January 20, 2017

LMC6032IM chip

LMC6032IM an Op-Amp IC doubles manufactured using CMOS technology. LMC6032IM It operates with two types of power supply, ie single and dual power supplies. LMC6032IM is able to generate gains of 12 dB and is often used for current-to-voltage converter, the pre-amplifier, integrator, medical devices, and so forth.

4N27 optocoupler

Optocoupler with phototransistor output
- Emitter Voltage: 1.5 VDC
- Behind emitter Voltage: 5VDC (max)
- Component output: NPN Phototransistor
- Output voltage: 70 V
- Output current: 50 mA
- Voltage isolation: 5000 Vrms
- The switching speed: 2 us
- Packaging: 6-pin DIP

AT90S2343-10PI micro chip

8-bit AVR microcontroller family.
- 2KB Program Code / w ISP Programming
- 128 Bytes of RAM
- 128 Bytes EEPROM
- One 8-Bit Timer / Counter
- SPI Interface
- PDIP-8 Package

ICL7106 chip

3½ digit ADC and outputs can be connected to the LCD
Technical specifications
- DC Power Supply = +6 V (V + to GND) and ?? 9V (V- to GND)
- Analog input = -9V s / d + 6V
- Voltage Reference = -9V s / d + 6V
- Display Output = LCD (Liquid Crystal Display)
- Power Dissipation = <10 mw="" p="">- PDIP-40 Package

PC814 chip

Photocoupler capable of receiving input AC voltage
- Emitter Voltage: 1,2V
- Voltage behind emitter: -
- Component output: NPN Phototransistor
- Output voltage: 35V (absolute max)
- Output current: 50mA (absolute max)
- Voltage isolation: 5000Vrms
- The switching speed: 18US (max)
- Packaging: 4-pin DIP

Thursday, January 19, 2017

Speaker 3inch 3watt

Speaker 3inch 3watt
- Diameter : 3" (inch)
- Impedance : 4 ohm
- Power : 3 watt

Wednesday, January 18, 2017

8 14 20 28 Pin SOIC To DIP PCB Adapter

an adapter board all-in-one that can function as a converter to convert to the type of packaging of electronic components into the packaging DIP SOIC. The adapter board capable of converting electronic components with packaging SOIC-8, SOIC-14 SOIC-20 SOIC-28 to DIP-8 DIP-14, DIP-20, DIP-28.

ITEAD Xbee Shield Module For Arduino UNO MEGA Nano DUE

A shield / breakout board is designed to allow you to connect to an Arduino XBee module. With this shield you can directly connect your own XBee module to the Arduino via the XBee socket which has been available on this shield. Shield has full compatibility of the module XBee Series 1 and Series 2, both the standard version and a pro version.

- Power Supply: 5 V
- Flow Output: 500 mA (max)
- Consumption Current: 20 mA
- Compatibility: Arduino Uno, Mega, Nano, Due, Duemilanove
- Dimensions: 54.9mm x 58.8mm x 1.6mm
- Indicators: PWR State, DI, DO, RSSI, ON, ASS
- Protocol: UART / XBee

Note: The sales package does not include modules XBee and Arduino

1N5234B 6V2/0.5Ampp zener diode

Zener diode with a voltage of 6.2 V and 0.5 watts of power.

Dot Matrix 2.4inch RED Super Bright 5x7 M type

dot matrix panel type M with a width of 2.4 inches. The panel has a resolution dot matrix 5x7 with total LED which as many as 35 pieces of each of these LEDs capable of emitting bright red light. Dot matrix panel is very suitable when used for the digital clock display, moving sign, running text, and so forth.

Tuesday, January 17, 2017

MCP604-I/P chip

MCP604-I / P is an IC Operational Amplifier (Op Amp) CMOS technology that is able to produce strengthening bandwidth of 2.8 MHz. MCP604-I / P can be applied as a driver ADC converter, pre-amp on the photodiodes, analog filter, data acquisition, notebook and PDA, and various other amplifier applications.

AD8302ARUZ chip

AD8302ARUZ an IC that serves to measure the value of loss, gain, and phase in various applications receiver, transmitter, and instrumentation. This AD8302ARUZ work at a working voltage of 2.7 - 5.5 V with a maximum input frequency of 2.7 GHz. AD8302ARUZ is normally applied to the data transmission system based on radio frequency (RF).

- Type: Amplifier Logarithmic
- Input Frequency: 2.7 GHz
- Phase Measurement Range: 90 degrees
- Dynamic Range: 58 dB
- Working Voltage: 2.7 - 5.5 V
- Output Voltage: 1.8 V (max)
- Working temperature: -40 ° C - 80 ° C
- Mounting Type: SMD / SMT
- Packaging: TSSOP-14


IRLL024NPBF mosfet

IRLL024NPBF an N-channel MOSFET with Vds 55V, 16V Vgs, and Rds 1 Mohm. These MOSFETs are ideal for switching applications.

AW101KE 100 ohm 2.5W resistor

AW101KE a 100 ohm resistor and power 2.5 W is designed to work in environments that require high physical endurance. This AW101KE able to handle applications with temperature, power, and implus high energy, so it is perfect when applied to the motor drivers, power devices, power converters, current limiting, and so forth.

RS501-BP 50V/5A Bridge Rectifier

RS501-BP is a diode bridge with a voltage of 50 V and a current of 5 A.

Monday, January 16, 2017

Pushbutton Switch 1 LED

Pushbutton switch SPDT (big knob) which has been equipped with 1 LED indicator. Color knob on the picture can be different to the color knob on the product.

Saturday, January 14, 2017


TXS0108EPWR an 8-bit voltage translator with a non-inverting configurations. Voltage translator is capable of transferring data at up to 110 Mbps in push-pull mode and 1.2 Mbps on the pull-up mode. TXS0108EPWR is usually used in handsets, smartphone, tablet, PC, and so forth.

- Channel Type: Bi-directional
- Number of Circuits: 1
- Number of Channels Per Circuit: 8
- A Port Voltage: 1.2 - 3.6 V
- Voltage Port B: 1.65 - 5.5 V
- Output Type: Open-Drain, Push-Pull
- Data Rate: 110 Mbps (push-pull)
- Working temperature: -40 - 85 ° C
- Features: ESD Protection
- Mounting Type: SMD / SMT
- Packaging: TSSOP-20

VNC2-32Q1B chip

VNC2-32Q1B is a USB host controller IC that is powered by a 256 KB memory e-flash, 16 KB of RAM, as well as 16-bit Harvard architecture to produce optimal performance. VNC2-32Q1B is often used in berantarmuka USB devices, such as USB storage drives, wireless interfaces OSI, the data logger, serial converters TLM, and so forth.

- Working Voltage: 1.8 - 3.3 V
- Architecture: Havard 16-bit
- RAM: 16 KB
- E-Flash Memory: 256 KB
- Protocol: USB 2.0
- Interfaces: UART, USB, SPI, FIFO
- Data Speed: 480 Mb / s
- Workflow: 25 mA
- Working temperature: -40 ° C - 85 ° C
- Mounting Type: SMD / SMT
- Packaging: QFN-32

MAX3243CAI chip

MAX3243CAI an RS-232 transceiver interface capable of transferring data at a maximum speed of 120 Kbps. This MAX3243CAI work at a voltage level 3 - 5.5 VDC and current consumption is very low at only 1 uA.

- Function: RS-232 Transceiver
- Data Rate: 120 kb / s
- Number of Drivers: 3 Driver
- Number of Receivers: 5 Receiver
- Working Voltage: 3 - 5.5 V
- Consumption Current: 1 mA
- Working Temperature: 0 ° C - 70 ° C
- Mounting Type: SMD / SMT
- Packaging: SSOP-28
- Pause Propagation: 0.3 us

ADXRS620BBG gyro sensor

ADXRS620BBG a gyro sensor BiMOS technology which has remarkable physical endurance and is designed so that can be applied to automotive and industrial environments. This sensor has the ability rejection vibration in a wide frequency and able to withstand shocks to the strength of 2000 G. ADXRS620BBG is ideal when used in automotive and industrial fields, such as chassis roll-over sensors on the vehicle, an inertial measurement devices, as well as stabilizing footing.

- Sensor Type: Gyroscope
- Type: Analog
- Axis: Z (Yaw)
- Range: 300 ° / s
- Sensitivity: 6 mV / ° / s
- Bandwidth: 10 MHz - 2.5 KHz
- Shock Resistance: 2000 G
- Output Type: Voltage Analog
- Working voltage: 4.75 - 5:25 V
- Workflow: 3.5 mA
- Features: Integrated with temperature sensors and bandwidth that can be configured
- Working temperature: -40 ° C - 105 ° C
- Packaging: 32-BFCBGA

12 pin FFC / FPC Connectors

FFC / FPC Connectors 12P SIDE ENTRY LOWER CONTACT SFV (10051922-1210ELF)

Connectors FFC / FPC female 12 positions with right-angle mounting angle.

Mini PICkit 2 & MCU Universal ZIF socket

Kit programmer for microcontrollers from Microchip. This kit is compatible with various types of microchip microcontroller like PIC, dsPIC, PIC32, etc.
- Power supply: +5 VDC (from USB)
- Compatible with a variety of chips from Microchip
- It has 3 LEDs as indicators (power, target, Busy)
- Has 1 buttons are used to start programming
- Available Universal ZIF socket for easy programming the chip in various packaging
- The sales package includes: 1x mini USB cable, 1x cable with two 6-pin connector, 1x 6-pin cable connector to RJ11, 2x male and 1x female header header
- Compatible with Windows 98 SE, Windows XP, or Windows XP

Friday, January 13, 2017

MB7383 HRXL-MaxSonar®-WRLST™

The weather resistant HRXL-MaxSonar-WR is a rugged, ultrasonic sensor component module. This outdoor sensor provides very short- to long- distance detection and ranging in a compact, robust PVC housing. The ultrasonic sensor meets the IP67 water intrusion standard and matches standard electrical 3/4‑inch PVC pipe fittings.

The HRXL-MaxSonar-WRLST MB7383 ultrasonic sensor features a maximum range of 10 meters to large targets. The MB7383 is our most sensitive long-range sensor.

High-output, acoustic power, combined with continuously variable gain, real‑time background automatic calibration, real‑time waveform signature analysis, and noise rejection algorithms results in virtually noise free distance readings. This holds true even in the presence of many of the various acoustic or electrical noise sources. The HRXL‑MaxSonar-WR sensors are factory calibrated to match narrow sensor beam patterns and provide reliable long-range detection zones.


  • Resolution of 1-mm
  • 6Hz read rate
  • Internal temperature compensation
  • 42kHz ultrasonic sensor measures distance to objects
  • RoHS Compliant
  • Read from all 3 sensor outputs: Analog Voltage, Serial, Pulse Width
  • Virtually no sensor dead zone, objects closer than 50cm typically range as 50cm
  • Operates from 2.7-5.5V
  • Low 2.9mA average current requirement
  • Small, light weight module
  • Designed for easy integration into your project or product
  • Operational temperature -40°C to +65°C (-40°F to +149°F)
  • Real-time automatic calibration (voltage, humidity, and ambient noise)
  • Firmware filtering for excellent noise tolerance and clutter rejection
  • Weather resistant (IP67), optional chemical resistant F-Option
  • Matches standard electrical 3/4-inch PVC pipe fittings for easy mounting (3/4-inch National Pipe Thread Straight)
  • Long, narrow detection zone
  • TTL Serial Output
  • Great for long-range people detection
  • Maximum range of 10 meters (394 inches)

2N6107 transistor

2N6107 is a PNP transistor with colector-emitter voltage of 70 V and a bandwidth of 10 MHz.

2SK2275 Mosfet

2SK2275 is N-Channel MOSFET with disapasi power 35 W, Vdss 900 V and 30 V. Vgss
